B-585 - Glass Oven Kugelrohr

The drying, distillation and sublimation of small quantities of substances

The ball tube oven is optimally suited for the fractioned distillation of small amounts of solvents up to 35ml and to a maximum temperature of 300°C.

Visual monitoring of the sample chamber, graphic display with manual and programmable mode. Adjustable temperature and time control, programmable for three steps. Variable rotation up to 50 U/min, vacuum and inert gas connection, integrated cooling. Overheating and protection against contact for the heating tube. Use of the rotation drying flask for quick drying without lumps. Optional automatic pump, on / off switch on termination of the program. Complete and ready to use including 1 rotation drying flask 60ml with vapor duct (DDR), 3 ball tubes 20ml with vapor duct, 1 cooling device, diverse standard accessories and operating manual.

Further Advantages

• to distil small quantities of substances
• for distilling solvents with low boiling points
• for rotational drying variable rotation up to 50 rpm
• temperature and time can be programmed at 3 levels

Bright And Clear Graphig Display

The bright, clear graphic display and a rotary/push button make the appliance particularly simple to use. The display has 6 different language options and the temperature can be registered in both °C and °F. 10 programmes can be stored in the integrated memory. To round off the innovation, an external vacuum pump can be switched on at the start of the programme and then off again on completion.

Ball Tube Distillation

The fractionated distillation process separates a multiple component mixture. In principle, as many balls as there are components in the mixture are connected together. The ball tube is then removed from the heating area ball by ball to enable the mixture to fractionate. The component with the lowest boiling point will condense in the outermost, coolest ball. To protect thermo labile substances the use of a vacuum is recommended.

Freeze Drying

With the new freeze drying insert, it is possible to lyophilise small product samples and acquire first indications of their drying behaviour. The design is particularly suitable for drying organic samples, for pharmaceutical and food-processing solutions as well as for extreme temperature conserving processes.
Due to the addition of heat via radiation, the substance is freeze dried quickly and evenly. This has particular advantages for secondary drying; the evacuated intermediate space prevents local defrosting caused by heat conduction.
