The generated hydrogen is diluted with fresh air through an ATEX-certified ventilator and discharged safely. The salt dissolving water comes from a softener integrated in the plant. Thus, lime deposits can be prevented and a long service life of the electrolytic cell can be ensured. The efficiency of the electrolysis is monitored by an integrated pH measurement of the sodium hydroxide production.

The plants are controlled with a modern PLC with large, illuminated display and integrated modem for remote diagnosis and troubleshooting.

• Robust, simple technology
• Compact, space-saving design
• Safe plant control with remote diagnosis via modem
• Low-chloride sodium hypochlorite with high chlorine concentration
• Economic operation thanks to the inexpensive raw material sodium chloride and less chemical consumption for pH value adjustment

• specifically suitable for applications where an ultrapure and low-chloride sodium hypochlorite is required
• Electrolysis plant mounted ready for operation on a powder-coated stainless steel frame with programmable logic controller (PLC) in control cabinet
• integrated softener
• electrolytic cell
• pH value monitoring
• ATEX-certified bleeding system and side salt dissolving tank with level monitor
• Level sensors to monitor the storage tanks for sodium hypochlorite to be provided by the customer
• Automatic monitoring of the water hardness downstream of the softener and chlorine gas detector for plants from 600 g/h
