The resulting chlorine gas is suctioned off through an injector integrated in the system and dissolved in the water to be treated as hypochloric acid. The generated hydrogen is discharged through a bleed line and the scaled down residual brine is disposed of. The sodium hydroxide is disposed of or optionally used with a metering pump integrated in the system to correct the pH of the water to be treated.

The salt dissolving water comes from a softener integrated in the plant, thereby preventing the formation of lime deposits and ensuring the long service life of the electrolytic cell. The microprocessor controller integrated in the system digitally indicates the actual feed rate and monitors all key functions. All operating and error messages are shown in plain text on the clearly arranged display. The feed rate can be controlled manually or externally.

• Robust, simple technology
• Compact, space-saving design
• Water disinfection and pH correction with one system
• Safe vacuum plant technology
• Production and metering of ultra-pure hypochloric acid
• Cost-effective operation thanks to the use of sodium chloride as an inexpensive raw material and lower chemical consumption for pH correction
• Optional integral chlorine and pH control

• specifically designed for smaller applications in private homes or hotels

• Electrolysis system is wired ready for operation with an injector system and dosing pump for pH correction (optional)
• Compact thanks to wall mounted design
• Integral water softening system with programmable regeneration
• Membrane electrolysis cell
