The salt dissolving water comes from a softener integrated in the plant. Thus, lime deposits can be prevented and a long service life of the electrolytic cell can be ensured. The efficiency of the electrolysis is monitored by an integrated pH measurement of the sodium hydroxide production.

The plants are controlled with a modern PLC with large, illuminated display and integrated modem for remote diagnosis and troubleshooting. The chlorine metering and the pH value correction are controlled as standard through contact inputs; analogue inputs are optionally available.

• Robust technology
• Compact, space-saving design
• Safe vacuum plant technology
• Production and metering of ultrapure hypochloric acid without intermediate storage
• Chlorination and pH value adjustment with one single plant
• Economic operation thanks to the inexpensive raw material sodium chloride and less chemical consumption for pH value adjustment

• suitable for all applications which require metering of hypochloric acid with simultaneous pH value correction

• Electrolysis plant mounted ready for operation on a powder-coated stainless steel frame with programmable logic controller (PLC) in control cabinet
• integrated softener
• electrolytic cell
• pH value monitoring of electrolysis
• ATEX-certified bleeding system and side salt dissolving tank with level monitor
• The scope of delivery also includes a central injector system matched to the plant to meter chlorine gas and sodium hydroxide, inclusive of a booster pump
• Automatic monitoring of the water hardness downstream of the softener and chlorine gas detector for plants from 600 g/h
