• Universal application because of combined control possible for many measured values. pH/Redox, pH/Chlorine, pH/pH, pH/Chlorine dioxide and Chlorine/Chlorine
• Optimum adaptation to processing requirements because different add-on stages
• Seamless integration into your processing technology: Varied installation options for sensors and different control options for dosing equipment
• Optimised process runs through special functions such as basic load dosing and many threshold value functions
• Safety: threshold value monitoring with dosing time limits as standard
• Simple and easy-to-view user guide in full text via a large graphic display in 8 languages
• Large, easy-to-read graphics display for measured values, correcting values and information.

Applications for measured quantity combinations pH/Redox, pH/Chlorine and Chlorine/Chlorine

• Water treatment for swimming pools
• Differentiating measurement of Chlorine, reduction of combined Chlorine in swimming pool water purification
• Cooling water treatment

Application for measured quantity combination pH/pH

• Effluent treatment
• Neutralisation
• All applications have to be fitted with a redundant pH measuring device for safety reasons

Application for measured quantity combination pH/Chlorine dioxide

• Combating legionella
• Drinking water treatment

• Threshold value monitoring with adjustable automatic cut-out as standard
• Probe connection in two-wire technology, unaffected by interference
• 2 signal outputs 0/4 – 20mA galvanically separated
• Different designs for wall and panel mounting
• 1 digital input for pause and error monitoring of sample water
• 1 digital input for super chlorination or basic load
• Basic load dosing (additive effect)
• Unidirectional control for pH/Redox, pH/Chlorine dioxide and pH/Chlorine, bidirectional control for pH/pH
• Neutral zone control for pH/pH
• Temperature compensation for pH
• Chlorine difference measurement for Chlorine/Chlorine
• Regulating output for minimising combined chlorine for Chlorine/Chlorine

ProMinent DULCOMETER Measuring and Control system uses DULCOTEST sensors and ProMinent dosing pumps to build a complete control system with measurement, control, dosage and recording, all from one source and optimised to work together.
