Manning - IR-F4 - Fixed Infrared Gas Sensor

The Manning IR-F4 can be used with Honeywell Analyitcs remote Readout/Alarm units that have built-in visual and audible alarms, as well as relay output for ventilation fan activation, central alarm tie-in, etc. The linear 4/20 mA output also can be fed directly into a computer control or PLC system.

Gas detection by the infrared method is based on the principle that most gases absorb infrared energy at a characteristic frequency. Any NH3 in the gas sample cell selectively absorbs energy reaching the detector. This change in energy is detected, amplified and sent to the signal processing portion of the system.

The sensor contains a pulsed infrared source, a gas sample cell, optical filter and a detector, which provides an electronic output that can be converted into gas concentration values.

Applications

• Food Processing Refrigeration Systems
• Chemical Manufacturing
• Gas Bottling Plants
• Ice Rinks
• Banana and Produce Rooms
• Beverage Plants
• Electrical Shutdown

Gas Specific

• Rapid response to target gas
• Ammonia detection up to 20,000 ppm
• Carbon dioxide detection up to 5% of atmosphere

Easy Maintenance

• Cost effective; no pump or dust filters required
• Lack of moving parts provides long-term maintenance-free operation

Reliable Operation

• Highly specific to ammonia
• Rapid response
• Modular electronics for ease of installation
• Linear 4/20 mA output

ATMOSTM Technology

• Allows for operation down to -50ºF and in condensing humidity environments or during washdown
• Automatically adapts to its environment and provides accurate and reliable performance under the harshest conditions
