• Regeneration in 30-45 minutes using SCION technology; minimizes down time, enhances bacterial control, improves chemical usage efficiencies
• PLC control and facia mounted display; facilitates monitoring and operation
• Continuous conductivity monitor with auto service shut-off and alarm; ensures water quality
• Continual, intermittent or zero recirculation of water when tank reaches high point; operational flexibility
• Skid-mounted, standardized systems; short lead times, quick installation and start-up

Extended Regeneration Option

• Removes need for separate post treatment
• Capable of producing water with <20 ppb of reactive silica; suitable for high and medium pressure boiler-feed
• Produces water of <0.1 μs/cm; polishing RO water (Strata+ Model)

Rapide Strata+ Model

• Integrated polishing device (Hipol)
• Produces water exceeding Ph Eur and USP conductivity requirements

Increased capacity and lower chemical usage means more treated water per litre of chemical and hence lower operating costs compared to conventional solutions. Rapide Strata challenges conventional thinking about ion exchange.

Stratified anion bed

• Highly efficient removal of organics; can tolerate up to twice as many organics in the feedwater than conventional solutions.
• Combination of anion resins increases capacity and results in higher quality treated water.

Pulse regeneration sequence

• Excellent chemical efficiencies compared to conventional solutions. Rapide Strata uses 20% less chemicals per m3 of treated water (40% less for Rapide Strata+).
• Greater removal of impurities and improved resistance to chemical and physical fouling compared to traditional solutions.

Short cycle ion exchange

• Regeneration in 30 to 45 minutes; maximizes production time
• Reduction in treated water storage requirements
• Minimal waste handling
• Increases bacterial control

Counter current regeneration

• Highly efficient use of chemicals

HIPOL integrated cation polishing device (Rapide Strata +)

• Polishes trace NaOH from anion resin
• Checks anion resin exhaustion
• Inferential silica monitor
• Water exceeding Ph Eur and USP conductivity requirements

Design & Manufacturing

• Skid-mounted, small footprint; facilitates installation
• Minimal start-up time
• Quality controlled manufacturing
• Standardized parts

Fully automated

• PLC controlled
• Facia mounted display with 5 language options
• Continuous conductivity monitor with auto service shut off and alarm
• Minimal operator involvement
• Optimal regeneration sequence
• Continual, intermittent or zero recirculation of water when tank reaches high level point

* Regeneration:

The RapideTM Strata+ has a 35 minutes regeneration for >1M -cm (<1μS/cm) water and up to 45 minutes regen for > 10M -cm (<0.1μS/cm)
