Master Magnets Ltd

Magnets for the aggregate & quarrying industry - Mining

The Master Magnets range of equipment protects crushers and other processing machinery from damaging tramp metals. Magnetic Separators are also used to remove any metal contamination from within the final product to ensure optimum cleanliness and maximum product value.

Tramp metal causes damage to conveyors, crushers, screens and other processing equipment. Magnetic Separators are used to remove ferrous metal contamination. Typical methods include:

  • Suspending a Permanent Overband Magnet (self-clean or manual clean) or Electro Suspension Magnet (self-clean or manual clean) across or over the head of a conveyor. Metal is lifted off the conveyor belt and either held on the magnet face or automatically discharged;
  • Replacing a conveyor’s head pulley with a Pulley Magnet. Ferrous tramp metal is attracted to the magnetic field and deposited underneath the conveyor out of the product stream;
  • Feeding material onto a heavy duty Drum Magnet. Magnetic material is attracted to the strong magnetic field and deposited underneath and away from the product;
  • Metal Detectors are commonly used alongside Magnetic Separators to detect tramp metal such as digger teeth (manganese steel). Used in combination, Magnetic Separators and Metal Detectors provide optimum protection. This results in less production downtime and reduced maintenance and repair costs.
