Scrap recycling plants for CRT screens - Waste and Recycling
Recycling of CRT monitors and flat panel displays will be possible by applying our well elaborated screen separating line. During CRT recycling, the glasses of the cathode ray tubes will be separated at the interface by means of the hot wire technique for being able to separately dispose the different types of glass, the luminescent layer loaded with pollutants as well as metals parts.
With the URT cathode ray tube separation device, type CRT, the so-called heat wire technology, front- and cone glasses of the cathode ray tube can be separated from each other. Front- and cone glass will be separated at the connecting line of both glasses.
The funnel glass is the lead containing, funnel-shaped rear part of glass from the cathode ray tube. A wire made of nickel-chromium alloy will be placed at the connectingline around the screen. The different glasses will be separated by a heating up and through the consequently resulting tension of the glass connecting line.
The fluorescent layer, which could be contaminant-laden, will be manually removed by the integrated vacuum cleaner, after opening the cathode ray tube. Subsequently the different types of glasses and the separated metal parts are transported to a further reutilisation. The fluorescent layer will be pulverulent collected in a collecting container.
