Chlorine Production From Table Salt Systems Spreading Out in Drinking and Wastewater Treatment Plants
Chlorine is the most used and preferred type of disinfectant in drinking water and wastewater disinfection, and now it is much easier for businesses to produce their own chlorine on site.
Chlorination has been the most widely used method for many years in the disinfection of high-volume water such as treatment plants, due to its residual and economical nature. The use of chlorine chemicals produced and transported as gas or liquid in Chlor-Alkali factories in drinking water, waste water or industrial facilities has disadvantages such as high occupational and environmental safety risk, odor problem in water, unavoidable environmental effects and additional costs. Chlorine production technology from salt eliminates all the disadvantages of commercial chlorination, enabling facilities to produce as much chlorine as they need on their own, using only table salt and electricity.
Kemisan, which develops and produces its technology in Turkey with its 45 years of experience in this field, has succeeded in switching many drinking water treatment plants from gas chlorine to salt chlorine technology in a short time and pioneered the widespread use of this technology in our country. Chlorine production from salt (chlorine generator) technology, which has positive effects on both our institutions, our people and our nature, has multiple benefits for institutions and businesses.
More Effective and Odorless Chlorine Production
During the water disinfection process, issues such as the cost of disinfectants to businesses and institutions, the disinfection ability of the chemicals used and the prolonged prevention of bacteria and microorganisms in water are gaining importance. Commonly used commercial chlorine - especially liquid chlorine - is combined with sodium hydroxide, although it is known to reduce its efficacy, in order to increase concentration during production and extend shelf life. However, fresh, active and low pH chlorine produced by chlorine generator is much more effective and superior in many respects than commercially supplied chlorine.
The mixed oxidant type salt chlorine generator, which is the most advanced form of chlorine generators and can be produced by a limited number of companies in the world, is not only more effective than commercial chlorine, but even more than all other disinfection types. The mixed oxidant type salt chlorine generator has many advantages in the field of public and human health thanks to its active, low pH sodium hypochlorite and oxygen-based strong oxidants produced with its high oxidation ability, as well as providing many cost-based benefits to the water treatment process of enterprises and institutions. Oxidizing iron, arsenic and mangan more effectively, destroying all organic and inorganic substances in the water line by oxidizing in long-term use, cleaning the biofilm layers in the lines and preventing their recurrence, completely eliminating the chlorine taste and odor in the water flowing from the fountain, reducing disinfection by-products, decreasing the need for chlorine to be dosed in water network lines over time, and allowing chlorine residue measurements that can still travel 2.5 times longer, are among the many advantages obtained by the use of chlorine generator from mixed oxidant type salt. The mixed oxidant type salt chlorine generator, which can produce only table salt, water and electricity, has become popular all over the world with its low operation costs and safe operation comfort it offers.
Technology That Ends Gas Chlorine Accidents
Enterprises that use chlorine gas, which is one of the commercial chlorine types with the lowest disinfection costs, constantly face the risk of gas chlorine leakage in their chlorine gas tanks and systems. Occupational safety risks of operators working in water treatment departments in treatment facilities or industry are the responsibility of the management staff. The fatal potential of chlorine gas accidents has led to the need to take the highest safety precautions in the facilities. However, in case of a gas chlorine accident within the facility, no matter how much precautions are taken, it is highly likely that the surrounding settlements and personnel will be heavily affected by the accident. The solution concentration produced by chlorine generators is less than 1%, eliminating the risk of gas chlorine and the security investments required during the use of chlorine gas. In this way, businesses and institutions provide a great advantage in occupational safety and health issues.
Stop High Dangerous Chlorine Gas Walking Around on Highways!
Due to its low unit price, chlorine gas is among the most preferred methods for disinfection of high amounts of water. Ironically, although chlorine gas is used to disinfect water for human health, it is also a very dangerous chemical that has deadly effects in direct contact. Transportation of such a dangerous product on highways during its transfer from production facilities poses a great danger to public health. One of the biggest advantages of switching to on-site chlorine production (chlorine generator) systems from salt is that it reduces the danger on the roads to zero by ending the commercial chlorine transportation. Thus, institutions and businesses prevent possible fatal chlorine gas accidents.
80% Less Transportation Requirements Compared to Liquid Chlorine
Shipping costs are one of the biggest hidden costs of treatment plants or process water treatment departments. A commercial liquid chlorine concentration between 12% and 15% means that the rest of the product consists entirely of water. Transportation of water is more occupied than chlorine needed during transportation, institutions and businesses spend the biggest transportation cost on water transportation rather than chlorine. However, on-site chlorine production systems from salt only need 2 tons of table salt to produce 10 tons of liquid chlorine. In this way, institutions and enterprises using on-site production system from salt need 80% less transportation for chlorine to be used in water disinfection compared to commercial liquid chlorine. Although the need for transportation does not show such dramatic differences between facilities using chlorine gas and those who prefer on-site chlorine production systems, the data obtained as a result of the return of empty tubes after use and deducting a certain amount of unusable chlorine from the total consumption show that only salt transportation is much less. This leads to considerable differences in operating costs.
The most important issue in terms of the sustainability of businesses or institutions is the financial burden of the disinfection method used. Products that are produced in Chlor-Alkali facilities such as gas chlorine and that require regular purchasing not only make institutions and businesses dependent on the chemicals produced by a small number of producers for disinfection process, but also bring the safety investments and heavy operating costs required for the use of these products. Many items such as transportation and storage of chemicals used, the need for expensive auxiliary chemicals to increase its efficiency due to the loss of concentration during storage, and the investments to the personnel required for the operation of all these chemicals and to be made for the occupational health and safety of the personnel, cause the costs to increase exponentially during water disinfection. However, on-site chlorine production systems from salt need minimum personnel during the disinfection process, minimize or even eliminate occupational health and safety costs. Furthermore, because the only raw material to be supplied from outside during chlorine production is any salt that can be obtained from many different vendors, it provides an enormous economic benefit to institutions.
Up to 50% Reduction of Disinfection Byproducts (DBP)
As it directly affects public health, it is essential that the water is at the levels and quality of the drinking water regulations set by the relevant ministries and units of the state. These limits are accepted as reference in drinking water treatment plants and it is ensured that the values of the organics it contains do not exceed these levels. Unfortunately, during the disinfection process, the reaction of chlorine with organic substances in water results in disinfection by-products known as Trihalomethane (THM) and Haloacetic Acid (HAA). One of the most important issues for drinking water treatment plants is the reduction of DBPs and keeping them below the specified limits. Thanks to the active oxidants contained in the mixed oxidant type salt chlorine generator, which is an advanced type of on-site chlorine production facilities from salt, it is possible to reduce the rate of DBP by up to 50%. In this way, while the desired amount of residual chlorine can be left in the city water network lines, the lowering of the DBPs to the minimum levels makes DBPs not a worrying issue for treatment plants.
Prevention of Biofilm Formation in Water Supply Network
The residual chlorine amount in the water is measured with samples taken from various points of the city in order to understand the continuous disinfection process in the water supply network. However, despite the measured residual chlorine, waterborne outbreaks are observed in certain parts of the city at certain times. The biggest reason for this to happen is the BIOFILM layer that forms and grows over time on the lines. Biofilm layers, with their slimy structure, provide a suitable environment for the microorganisms in the water to reproduce by trapping them. The biofilm layer, which is resistant to chlorine, provides strong protection for microorganisms, against especially chlorine. Microorganisms multiply rapidly in this safe environment, and the biofilm layer tears at some point. This causes all the microorganisms that have multiplied to disperse in the flow direction of the water network, and the residual chlorine content in the water becomes unable to cope with the high amount of bacteria in a short time. Mass epidemics may suddenly appear in certain parts of the city as a result of the spread. While chlorine alone cannot prevent biofilm formation, it cannot also destroy existing biofilm layers at the same time. Mixed oxidant type sodium hypochlorite generators; in other words, on-site chlorine production plants from salt eliminate the biofilm layer in all water supply network without the use of any other chemicals, while at the same time completely preventing its formation.
Local and National 45 Years of Experience
There are few companies in the world that develop, design and manufacture chlorine production systems from salt. Apart from designing chlorine production facilities from salt, specially coated titanium plates, that produce the solution obtained for the disinfection process and form the `` cell `` part called `` anode `` and called the heart of chlorine production systems from salt, can be produced by only major companies all over the world. Kemisan company, which has been operating in Izmir for more than 45 years, designs on-site chlorine production facilities from salt with 100% locally and nationally produced anodes and supplies the mixed oxidant type sodium hypochlorite generators it produces to many water treatment plants in Turkey.
Exemplary Institutions and Businesses Transitioning to Future Technology in Turkey
Despite the fact that there are few producers of chlorine from salt and mixed oxidant type sodium hypochlorite production systems in the world, one of the companies that have developed this technology in the best way is a Turkish company with a hundred percent domestic capital and 45 years of experience. It enabled the private enterprise to rapidly switch to this technology. The institutions listed below have been using these systems, which can be applied to many different sectors, and have been using them for a long time;
- ASKİ (Ankara Municipality Water and Channel Administration) Pursaklar
- Kocaeli İzmit Municipality Water A.Ş.
- GASKİ (Gaziantep Municipality Water and Channel Administration)
- Sivas Şarkışla Municipality
- SİBESKİ (Sivas Municipality Water and Channel Administration)
- ESKİ (Erzurum Municipality Water and Channel Administration)
- ESKİ Erzurum Karayazı Treatment Facility
- Afyonkarahisar Central Municipality
- Gümüşhane Central Municipality
- İSU (İzmit Water) Avluburun Drinking Water Treatment
- Kocaeli Kandıra Drinking Water Treatment
- Kocaeli Gebze Treatment
- Uşak Drinking Water Treatment Facility
- Uşak Central Municipality
- Manisa Drinking Water Treatment Facility
- Bolu Central Drinking Water Treatment Facility
- Burdur Drinking Water Treatment Facility
- Edirne Drinking Water Treatment Facility 1
- Edirne Drinking Water Treatment Facility 2
- Galata Port Facilities
- Erdemir Iron and Steel Facilities
- Granada Luxury Belek Hotel
