The following is an essential knowledge for selecting most effective and economical ozone system:

I am often asked if Absolute Ozone® uses cold plasma technology to produce ozone?

Let us start from the fact that all gas ozone generators on the market are basically the same and use the same principle technology. Two electrodes cylindrical or flat, dialethic that is typically ceramic or quartz and oxygen gas as a second part of the dialectic. Therefore all the names of the technology “cold plasma, corona discharge, dialectic barrier discharge, etc., are just different names of basically the same principle and could be OK for marketing purposes for people who do not understand the simplicity of the technology, but are completely irrelevant in ozone generator selection process.



FROM CUSTOMER POINT OF VIEW ONLY THE FOLLOWING PARAMETERS ARE REALLY IMPORTANT:

 GENERATOR`s QUALITY: how many ozone generators per thousand come with manufacturing defects. Absolute Ozone® has less than 3 per thousand that fail

 CONSUMABLES & RELIABILITY: How many components for the generator has to be replace in 1, 5 or 10 years of use and how many times the generator have to be repaired. Absolute Ozone® generators design to work for over 20 years period (and we have many in the field working over 20 years) without any service or spare parts.

SERVICEABILITY: Could the ozone generator to be easily repaired locally.

Absolute Ozone® generators do not require any service and most parts are not field serviceable, that said all parts and components could be replaced in the field by any qualified electronic technician without special training.

CUSTOMER TECHNICAL SUPPORT: How easy it is to receive the support, how long it last and how much it cost.

Absolute Ozone® Offers free unlimited support not only for the generators, but with customer applications, sizing, tuning, troubleshooting, system optimization, installation and commissioning, unmatched by any other ozone company.

Generator Warranty:

Absolute Ozone® generators offer one of the best 5 years warranty.

 COMPACTNESS: Smaller ozone generator is less expensive to ship and to install as you do not need any forklifts or many workers to carry the equipment.

Absolutes Ozone® produces the most compact and light weight ozone generators in the industry.

 OZONE PRODUCTION: Unfortunately, most of the ozone generator manufacturers exaggerate their ozone generator performance or measure it while the generator is still cold and did not reach the operating temperature. So when you are buying 30 g/h ozone generator you can get a generator that produces only 24-28 g/h or less at specified ozone concentration.

Absolute Ozone®: guarantees ozone production and in unlikely event of the generator not performing according to publish specifications will replace it or refund the money back to the customer. Not just ozone production but the ozone concentration as well.

  VALUE: How much ozone per every dollar you spend on purchasing and operating the generator can dissolve in your water for treatment or into gas flow or room per hour as an example for killing viruses.

 OZONE CONCENTRATION:

A very important and most neglected fact in the ozone industry is that majority of people working with ozone do not realize that not all ozone produced by a generator is possible to dissolve in water. The laws of physics and Henry’s Law of dissolving gases in liquids in a nutshell dictates (in simplified terms) that the higher is the ozone concentration the more ozone you can dissolve in water. If you like to learn more about science on this subject, I will be happy to assist. You should know that for the past 150 years nobody was able to disprove accuracy of these laws as they were proven over and over again experimentally.



 In our tests we have seen a following dependency:



 Ozone Concentration              Amount of Ozone Dissolved From Total Produced



 1%wt.                                     ~10% Maximum for dry air fed air-cooled ozone generators

3%wt.                                     ~20 - 30% Over 90% of all ozone generator manufacturers work in this range

5-7%wt.                                  ~50 - 70% Absolute Ozone® typical NANO, Atlas, Magnum generator performance and just a few other generators

8-10%wt.                                 ~80 - 90% Absolute Ozone® Atlas 30 performance, plus most good quality water-cooled generators

10%wt.                                   ~95% Atlas 30 at low flows and most good quality large size water-cooled generators

14%-22wt.                              ~97% Atlas 30 at low gas flows and just a few water-cooled ozone generators.



We used cold water and correctly tuned Venturi injector for injection.

If bubble diffusers are used the dissolve efficiency will respectively drop down about 7-10 times.

If average customers knew this information, they would never buy ozone generator from most ozone generator manufacturers and that would force them to disappear or to start making good performing ozone generators that are considerably more expensive to produce than the substandard systems they make today.



Bear in mind, that most of the ozone generator manufacturers are trying to hide the fact that their generators have poor performance by lying in their advertisement.

i.e. Pacific Ozone says that their ozone generators work at 5-8%wt, however when we tested few of them, we could not get higher than 2.7%wt.



Unlike Absolute Ozone® unfortunately none of the North American and Asian ozone generator manufacturers guarantee their generator’s performance, so they could lie as much as they want in their specifications and cheat their customers.
