AEGIS Flow Technologies, L.L.C. products

The Aegis LBR series valves are low torque, fully lined, high performance ball valves engineered for industries most hazardous and corrosive processes. The valves provide an excellent ratio of economic and operational performance in a wide variety of process applications. They serve as a reliable alternative to lined plug valves due to higher flow rate, lower torques, and minimum maintenance.

The Aegis LBF series valves are ideally suited for the stringent performance requirements demanded with wet chlorine gas and aqueous hydrochloric acid applications. The LBR series valves are designed to offer long-term maintenance-free security against the harmful effects of fugitive emissions. Valves for chlorine service are thoroughly cleaned and packaged according to our factory procedures and conform to the Chlorine Institute Pamphlet #6 specifications.

The Aegis BFV series fully lined high performance butterfly valves feature the most advanced technology available for controlling and isolating corrosive, ultra-pure, and highly-toxic process liquids and gases. The BVF series valves are designed, engineered, and manufactured under a company-committed quality assurance process that has been audited and approved by the SQS ISO 9001:2000 for Quality and Management Systems and the PED (Pressure Equipment Directive) 97/23/EG for mechanical integrity. The unique geometric profiles of the disc and liner eliminate the cold flow and deformation issues typical of conventional lined butterfly valves, resulting in a conditional, environmentally safe, life time shaft seal guarantee.

The Aegis LPG series valves are ideally suited for the stringent performance requirements demanded with wet chlorine gas and aqueous hydrochloric acid applications. The LPG series is designed to offer long-term maintenance-free security against the harmful effects of fugitive emissions. Our standard innovative three point system has revolutionized the performance benchmark for lined plug valves.

The Aegis LDV/SC series are fully lined composite body diaphragm valves. The LDV/SC valve offers an ideal solution to process condition where internal and external corrosion issues exist, as well as application where electrolytic corrosion and weight are concerns.

The Aegis® weir style diaphragm (LDV) valves feature the most advanced technology available for controlling and isolating extremely corrosive and toxic process fluids and gases. All valves are manufactured utilizing modern computer-aided production methods and molding technology, guaranteeing control of the manufacturing process and reduction of rework thus assuring defect free products that are delivered on time. Each valve is tested and certified per the API 598 specifications and the DIN 3230 part 3, leakage rate 1 specifications for absolute bubble tight shutoff and zero stem leakage.

Aegis HPCV series high integrity ball valves feature the most advanced technology available for isolating and controlling industries` most hazardous process liquids and gases. HPCV series are routinely specified to satisfy the stringent safety requirements associated with processing and handling Dry liquid Chlorine and Anhydrous HCL.

The Aegis ESV series ball valve performs a crucial task of providing positive shutoff during rail car unloading. Its emergency shut off feature ensures that the valves stops flow in case of damage to the line or valve ensuring a safe offloading process.

Offered in 90 or 180 degrees Rotating Actuator - Double Acting, Spring to Close or Spring to Open Designs, Guaranteed for 1000000 Continuous Cycles, Permanently Lubricated maintenance free design, Low Coefficient of Friction Piston Bearing Eliminates Metal to Metal Contact with the Housing, ISO 5211 DIN 3337 Flange Drilling, Internally Mounted, Blow Out Proof Pinion Shafts, Exceptional External Corrosion Protection Provided by the Enviroguard System

The Aegis® RSS series valves are specifically designed for flow control of corrosive, hazardous and ultra-pure process fluids and gasses. The RSS series is especially suitable for media where stainless steal and exotic alloys do not provide sufficient corrosion resistance, as an economic alternative to exotic alloy valves, for metal-reactive media, for biotechnology and high-purity media where excellent cleaning and anti-adhesive surfaces are important, and for highly permeating media.
