AGI Hi Roller products

Available in belt widths from 18" to 54", this is our original model. The unique bell-shaped carrying idler provides the trough for the belt and utilizes two external bearings as opposed to the six internal bearings associated with a conventional idler. The bell-shaped idler also has built-in self aligning characteristics for both single and bi-directional conveyors.

The heaviest duty, highest capacity and longest life enclosed conveyor available. Ideal for handling large capacities and continuous plant feed applications that run 24 hours a day, seven days a week. Resembling a conventional conveyor idler, the Hi Life® idler is much thicker, the bearings are much larger and there are no brackets or bearings exposed to the internal atmosphere of the conveyor housing. Considered the industries best conveyor for handling abrasive products.

Available in belt widths from 16” to 36”, the Mini Roller includes all the benefits of the Hi Roller in a lower profile design. The bell shaped carrying idler, head, and tail pulleys all have a smaller diameter. This conveyor is well suited for low capacities.

As with all Hi Roller conveyors, the Lo Roller®?is custom designed and built to your specific requirements. Hi Roller®?will assist you to determine the best combination of performance and cost to provide you with the safest, most cost effective solution to suit your needs today and in the future.

By incorporating a stationary tripper, product can be discharged intermittently. As the conveyor belt passes through a series of pulleys, the conveyed material is discharged off of the belt.

Although our specialty is totally enclosed belt conveyors, we offer many open top, enclosed bottom belt conveyors using intermediate moveable plows or trippers to distribute product along the length of the conveyor.

Product can be conveyed bi-directionally without giving up the reloading feature of Hi Roller® enclosed belt conveyors. By incorporating a reloading valve on either end of the conveyor, returned product is reloaded back on to the conveyor belt. Without such a feature, product contamination could occur by allowing spilled product to discharge into incorrect spouting or storage.

Designed based upon the product trajectory of your specific conveyor, our two-way flop valves allow you to discharge product into two separate spouts utilizing minimal height. Unlike a conventional two-way valve positioned under the conveyor discharge, our valve is a part of the discharge. The individual output spouts can be designed to meet your specific spouting dimensions and angles.

Many types of gates can be incorporated into our conveyor inlets. This eliminates the need to coordinate sizing amongst multiple vendors. Along with the customization of our conveyor inlets, we will design, manufacture, and mount the gate directly to our conveyor inlet. Our inlet will capture any dust that may escape the underside of the gate and drop that dust on to the conveyor belt.

V-wheels which support and guide the tail assembly as the belt is tensioned. Optional load cell to monitor belt tension. Optional display to be used in conjunction with load cells (alternatively, load cell signals may be sent directly to you PLC).
