Allied Furnaces Pvt. Ltd. products

Pioneers in this field with an installation way back in 1980s. Largest number of rotary kiln references in this country. Most versatile and best suited for all types of waste. Defacto option, if waste input conditions are unknown. Suited for wastes with high inorganic content. Have re-designed systems to suit high salt content wastes. The highest level of flexibility for simultaneously processing a wide variety of mixed waste streams with large variations in heating value. Supports wet and dry ash removal. Can be designed for slagging or non-slagging modes. Supports different forms of waste charging. Special sealing to avoid infiltration and leakages. Special lining to suit waste characteristics. Automatic ash handling systems can be integrated.

Best suited for bulky wastes, Avoid shredding / waste preparation, Suited for wastes with higher ash/ inorganic content, Batch operation, Double side bogies to reduce idle time, Suited of highly varied waste sizes and properties, Special sealing required to avoid infiltration and leakages, Both bogie and chamber are refractory lined, Ash remains on bogey, and is removed manually.

Systems are provided with latest in instrumentation, automation and control.

Best suited for small and medium organic wastes, Ideal for solid organic waste, liquid organic waste, gaseous wastes, VOCs etc., Hopper with double flap valve for waste charging, Refractory lined as per temperature duty required, Easy design and built, Port holes for poking and raking, Ash Door for de-ashing, Batch / continuous operation depending on de-ashing frequency, Ash bin trolley for ash collection and disposal.

Type of stationary chamber for drummed waste, Suitable for disposal of tarry / semi-solid wastes which are difficult to handle, Open top drum is directly loaded, Works on principle of pyrolysis, Drum detoxification.

Suitable for gaseous waste with high volatiles, Suitable for Corrosive gasses, like chlorine, fluorine, H2S gas etc., Waste gas is administered into chamber through flame arrestor and seal-pot to avoid flashback, Heat recovery is possible depending on flue gas characteristics.

Suitable for gasses with low VOCs, Gasses are pre-heated in ceramic modules before oxidizing, Direction of flow is reversed using valves/dampers, Ceramic honeycomb modules used as media, High operating economics, 2 bed or 3 bed systems.

Suitable for gasses within LEL bandwidth containing VOCs, Gasses are pre-heated in heat exchanger before oxidizing, Closed loop system, High heat recovery in form of hot-air, steam possible, Best suited for coating lines, paint booths etc.

For HCl, Hg and Dioxin control, Regent system with lime and carbon dosing, Pneumatic conveying of regent, Surface adsorption by Pulse Bag-filter.

Venturi scrubber, Packed column scrubber, Carbon bed scrubber, Demister, Caustic dosing, Recirculation system.
