Anping Shengjia Hardware Mesh Co., Ltd.

10 products found

Products

  • Derrick

  • Derrick - Model FLC - SJ-PWP - 2000 - Shale Shaker Replacement Screens

    Derrick - Model FLC - SJ-PWP - 2000 - Shale Shaker Replacement Screens

    SJ-PWP 2000 shale shaker screens, also famous known as 48-30 screens, are compatible with Derrick FLC (Flo-Line Cleaner) 2000 series shale shakers. It is a hook strip flat type shaker screen, which is constructed of multiple stainless steel 304 or 316 wire mesh cloth layers. And then bonded to a rectangular or hexagonal perforated metal plate for added support and facilitation of repair.

  • Derrick - Model FLC - SJ-PMD - 2000 - Shale Shaker Replacement Screens

    Derrick - Model FLC - SJ-PMD - 2000 - Shale Shaker Replacement Screens

    SJ-PMD 2000 shale shaker screen is manufactured based on the innovated design of Derrick Corporation. This type of shaker screen is constructed of multiple layers of stainless steel wire mesh cloth with different densities. Arrange these layers reasonably and exactly, the finished shale shaker screen with revolutionary three-dimensional corrugated screens structure. Pyramid screens offer 125% to 150% usable areas of traditional flat...

  • Derrick - Model FLC 500 - Flat Shaker Replacement Screens

    Derrick - Model FLC 500 - Flat Shaker Replacement Screens

    FLC 500 flat shaker screen is designed for the replacement screen of Derrick FLC 500 series shale shakers. It is constructed with two or three layers of 304 or 316 stainless steel wire mesh cloth, and then combined together with a steel backing plate. The FLC 500 PWP screen features a single side quick-lock tension system that reduces panel replacement time.

  • Brandt

  • Brandt - Model SJ-VSM 300S - Scalping Shale Shaker Replacement Scalping Screens

    Brandt - Model SJ-VSM 300S - Scalping Shale Shaker Replacement Scalping Screens

    SJ-VSM 300S scalping shale shaker screen is manufactured as the replacement screen for Brandt VSM 300 shale shaker. It is installed on the top deck of the VSM 300, which are used to scalp off large volumes of solids. Thus protecting the finer mesh of the lower deck (primary) screens. The scalping screen is usually sized from API 10 to API 325, ShengJia...

  • Brandt - Primary Shale Shaker Replacement Scalping Screens for Lower Deck

    Brandt - Primary Shale Shaker Replacement Scalping Screens for Lower Deck

    SJ-VSM 300P primary shale shaker screen is manufactured for the replacement screen which compatible with Brandt VSM 300 shale shaker. It is installed on the lower (primary) deck of the VSM 300 which mounted on a constant 7° ramp. Primary screen offers a higher throughput capacity and ensures consistent conveyance of solids thus minimize the solids build-up.

  • Swaco

  • Swaco - Model SJ-M/M - Shaker Replacement Screens

    Swaco - Model SJ-M/M - Shaker Replacement Screens

    SJ-M/M shaker screens have steel and PT frame types for your choice. Both of them are ideally as the replacement screens of SWACO MONGOOSE PRO and MEERKAT PT shale shakers. MONGOOSE units have 4 pre-tensioned screens per shaker basket and the MEERKAT units have 3 pre-tensioned screens per shaker basket. The mesh types are XR, XL, HC, MG available. AS a manufacturer, we provide adequate inventory and caring services unique for...

  • Swaco - Model SJ-MD-2/3 - Shaker Replacement Screens

    Swaco - Model SJ-MD-2/3 - Shaker Replacement Screens

    SJ-MD-2/3 shaker screen is a kind of composite frame shaker screen specified for both M-I SWACO MD-2 dual flat-deck shaker and MD-3 triple-decker shale shaker. M-I SWACO MD-2 shale shaker is suitable for both onshore and offshore applications and MD-3 triple-decker shale shaker mainly targets primarily high-end offshore operations. Reinforced PT frame reduces the friction between the screen and deck plate. Featured by higher...

  • Kemtron

  • Kemtron - Model SJ-KTL-48 - Replacement Shaker Screen

    Kemtron - Model SJ-KTL-48 - Replacement Shaker Screen

    SJ-KTL-48 shaker screen is the replacement screen which is compatible with KEMTRON 48 series shale shakers. For maximizing the solids removal and discharge dryness, please contact us for ideal screen selection advice according to the practical flow rate and solids type. Please don't attempt to use sealant to extend the life of the screen, screen saver plugs are the wise choice and will seal off any broken cell within the screen.

  • Scomi

  • Scomi - Model SJ-SG - Steel Frame Shaker Screen

    Scomi - Model SJ-SG - Steel Frame Shaker Screen

    SJ-SG shaker screen, also commonly called Scomi prima 3G/4G/5G screen, refers to the replacement screen for Scomi Prima series shale shakers. The main shaker models are including SCM-PrimaG 3P/4P/5P linear motion shale shaker and SCM-PrimaG 4PDD cascading shale shaker. Screen quantity correspondingly varies by the different shaker models. The whole screen cloth is divided into independent small surfaces by rectangle perforated holes...
