Applied Concepts, Inc. products

The Stalker Pro II Surface Velocity Radar (SVR) offers advanced water flow management capabilities. Drawing on decades of microwave radar expertise and featuring direction-sensing software, this device is designed for precise and reliable water flow measurement. Its Ka Band performance surpasses that of competitor models using K Band, and the SVR includes automatic vertical tilt compensation for accurate readings from varying angles. The radar's sensitivity ranges from 0.2 m/s to 18.0 m/s with an accuracy of ±0.1 m/s, and it supports multiple units of measurement including meters/second and miles per hour. Additionally, the SVR is powered by a Digital Signal Processor (DSP), which enhances performance consistency and allows for future upgrades via software updates, reducing obsolescence. The device is robust with a cast-metal exterior, various sensitivity levels, and the ability to sense flow direction. It operates efficiently on a power supply of 9-16 VDC with current specifications of 470 mA when the transmitter is on. This product aims to set a new standard in the industry.

The Stalker Traffic Speed Sensor is engineered to meet the demands of both moving and stationary monitoring applications, making it ideal for road traffic and speed management in mobile environments. Although not intended for use in speed enforcement within the U.S., this sensor incorporates high-performance features typically seen in law enforcement traffic radar devices. It offers speed locking and Doppler audio output capabilities. The sensor operates on a voltage range of 9-24 VDC and consumes 370 mA with the transmitter on. It functions efficiently across a wide temperature range from -22°F to +158°F. The sensor supports a configurable low-speed threshold from 1 MPH to 200 MPH, and tracks patrol speeds from 1 to 90 MPH, with advanced settings for higher thresholds. Its maximum tracking capabilities include opposite lane target speeds up to 200 MPH and same lane patrol speeds with ±70% accuracy. Featuring a microwave specification of 10 to 25 mW, the sensor is designed for high accuracy and reliability in diverse environmental conditions.

The Stalker Stationary Speed Sensor is designed for fixed-position speed measurement in various outdoor conditions. Its waterproof housing makes it suitable for any outdoor location where stationary speed measurement is required. It operates on 9-24 VDC with a current of 370 mA when the transmitter is on and 100 mA when off. The sensor allows for configurable low speed thresholds ranging from 1 MPH to 200 MPH. Its microwave specifications include a minimum output of 10 mW and a maximum of 25 mW, making it a robust solution for precise speed detection. The unit is configurable via a range of software tools and configuration files, with newer software versions offering enhanced functionality though not backward compatible. This sensor is essential for applications where precise, fixed-location speed measurements are necessary, providing detailed and reliable performance in various environmental conditions.

The Stalker Stationary Statistics Sensor is a high-performance device designed for monitoring and recording traffic patterns on roadways in diverse environmental conditions. It is a self-sufficient system capable of tracking up to 10 moving vehicles simultaneously and can function as a standard speed sensor, transmitting the strongest and fastest target information to external systems via RS-232, RS-485, or USB interfaces. This sensor is well-suited for deployment in pole-mounted displays, speed signs, and speed trailer applications. The device is integrated with an Internal Real-Time Clock for accurate date-time stamps and is compatible with the Stalker Traffic Analyst Application, facilitating detailed data analysis by count, speed, and other metrics. The unit operates with low power requirements and can be configured using an intuitive PC Graphical Interface, the Sensor Wizard Application. The device supports multiple sensors connected to a single controller through an RS-485 connection and is available in an open board version for embedded use inside protective housings.
