B&A Trailers products

Model: 720T8T. GVWR: 16,000 lbs. Main Frame: 8" structural channel (8" l-Beam gooseneck package). Inside cross members: 3" channel (16" on center). Deck height x width: 23" x 80" inside fenders. Flatbed: 20` wood (16` & 18` available). Ramps: 5` spring assist.

Model: 720T7T. GVWR: 14,000 lbs.. Main Frame: 7" structural channel (8" l-Beam gooseneck package). Inside cross members: 3" channel (16" on center). Deck height x width: 22" x 82" inside fenders. Flatbed: 20` wood (16` & 18` available). Ramps: 5` spring assist. Sides: stake pockets and rub rail. Jack: Ram 12K drop leg. Coupler: adjustable hitch w/ 2 5/16" bail or 3" pintle eye. Axles: (2) 7,000 lb. 4" drop spring suspension, EZ lube with electric brake. Wheels: 16" single, 8 lug. Tires: (4) - 235 80 R 16 E, 10 ply radials. Spare Tire: mounted front bulkhead. Storage: mesh bottom floor in tongue (w/ locking lid). Fenders: 1/8" checker plate. Floor: 2" x 8" Pressure treated pine. Breakaway kit: 12 Volt battery, with charge wire and LED test light. Safety chains: (2) 3/8" w/ hook and closures. Wiring: run in conduit tubing with junction boxes and neatly spliced. Lights: LED. Paint: cleaned, primed and painted 100% Black (optional color). Warranty: 1 year with MSO provided.

Model: 720T7TT. GVWR: 14,000 lbs. Main Frame & tongue: 6" structural channel (8" l-Beam gooseneck package). Inside frame cross members: 3" channel (16" on center). Bed Main tilt frame: 6" channel. Tilt Bed: 16` wood (18` available). Front Stationary: 4` wood.

Model: 720T8TT. GVWR: 16,000 lbs.. Main Frame: 7" structural channel (8" l-Beam gooseneck package). Inside frame cross members: 3" channel (16" on center). Bed Main tilt frame: 7" channel. Tilt Bed: 16` wood (18` available). Front Stationary: 4` wood. Cylinder: 2" bore gravity feed self-dampening cylinder w/ reservoir & flow-speed control. Tongue: 5` (wrap under double frame). Width: 82" inside fenders, 80" deck (75" wide tilt bed)

Model: 8.524T8T. GVWR: 16,000 lbs. Main Frame: 10" l-Beam (W10xl5) {10" l-Beam gooseneck package). Inside cross members: 4" channel. Top cross members: 3" channel (16" on center). Deck Height/ Width: 34"x 102". Flatbed: 20` wood. Beavertail: 4` wood.

Model: 8.524T7T. GVWR: 14,000 lbs. Main Frame: 10" l-Beam (WW x 12) (8" l-Beam Gooseneck). Inside cross members: 4" channel. Top cross members: 3" channel {16" on center). Deck Height/ Width: 34"x 102". Flatbed: 20` wood.

Model: 8.525T10T. GVWR: 20,000 lbs.. Main Frame: 10" l-Beam. Inside cross members: 7" & 4" channel. Top cross members: 3" channel (16" OC). Deck Height/ Width: 34"x 102". Flatbed: 20` wood.

Model: 8.525T20T. GVWR: 48,500 lbs. Load Capacity: 40,000 lbs. Main Frame: 14" l-Beam. Inside cross members: 6" channel. Top cross members: pierced frame 4" channel (16" OC). Deck Height/ Width: 35"x 102". Tongue: 5`. Flatbed: 20` wood. Beavertail: 5` wood.
