BETE Europe GmbH products

Design Features of the MP nozzle: Ultimate clog-resistant design with largest free passage available in a full cone nozzle. Two unique S-shaped internal vanes allow free passage of particles. High energy efficiency. Easily handles dirty, lumpy liquids. Male and female connections. Flanged connection available.

Design Features of the WL nozzle:  Advanced whirl plate design produces uniform coverage.  Male and female connections.  Spray Characteristics:  Medium to coarse atomization.

Design Features of the SC nozzle : Complete line of full cone nozzles made in cast metal alloys. Internal removable vane. Male and female connections. Flanged connections available. For plastic nozzles, see NC or MP nozzles.

Design Features of the MPL nozzle: 1/8 and 1/4 pipe connection sizes. Ultimate clog-resistant design, with thelargest free passage available in an axial, full-cone nozzle. Unique, S-shaped internal vanes allowfree passage of particles. High-energy efficiency. Easily handles dirty, contaminated liquids. Male connections. Nozzle body available in Brass, 303, 316 Stainless Steel. Vanes are 316 Stainless Steel foroptimum wear and corrosion resistance.

Design Features of the NCJ nozzle narrow spray angles. High velocity. Male and female connections. Flanged connections available. Available in plastic and metal alloys.

Design Features of the HA nozzle: Standard 3-piece construction. Male connection. Special spray angles on request

Design Features of the NF nozzle: One-piece construction. No internal parts. Sizes for all applications. Male connection.

Design Features of the NFS nozzle:  Extremely short length for minimum projection and maximum clearance.  Produces a flat fan spray pattern available in a variety of spray angles.  Available in straight (parallel) threads only, NPS and BSPP. Requires gasket to seal connection.

Design Features of the NF nozzle: One-piece construction. No internal parts. Sizes for all applications. Male connection.

Design Features of the PSR nozzle: Small physical size. Small orifice size: 0.014" through 0.125" (0.035mm through 3.18mm). Interchangeable with most other needle-type showers
