BIOFerm™ Energy Systems products

The BIOFerm system is a batch type system that uses the principle of dry fermentation anaerobic digestion in the mesophillic temperature range. The BIOFerm dry fermentation process is well suited for solid waste materials that have a solids content of 25-35%.

The PASCO charger technology for solid matter is part of our product range. This charger system is able to process large amounts of solid manure and grass without problem and without consuming much power. The flexibility of this charger technology is remarkable: Many combinations can be accommodated, from 14 to 80 m3 of all imaginable raw materials, including the most versatile discharge and handling technologies (moving floor, screw conveyor system, high level handling, delivery through the ceiling and soon, even feeding below fill level). Currently, the first plants are being equipped with concrete charger systems.

EUCO is a plug flow digester with agitation that is designed to run at the mesophillic temperature range. The steel tank has a rectangular footprint and has a horizontal paddle mixer than runs the full length of the tank. The mixer is powered by planetary drive units at both ends. The tank is heated through the horizontal mixer shaft. Solid material is loaded into the tank via the PASCO feeder system. Liquid feedstock is pumped from a CALIX reception pit.
