Blagdon Pump products

Metallic Pumps

Blagdon - Metallic Pump

Material options suitable for a wide range of applications. Simple construction, easy to maintain. Self-priming, ideal for emptying containers. End ported for improved flow. Pressures to 8.6 bar (125 PSI). Flow rates up to 180 litres/minute (48 gal/min). Bolted construction for greater integrity. Weighted valve balls for high S.G. and viscous fluids. Reliable pneumatic air valve.

Blagdon - Metallic Pump

Simple construction, easy to maintain. Self-priming, ideal for emptying containers. High-quality investment cast design. Pressures to 8.6 bar (125 PSI). Flow rates up to 320 litres/minute (85 gal/min). Bolted construction for greater integrity. Reliable, proven pneumatic air valve system.

Blagdon - Metallic Pump

Air valve designed for in-line maintenance. End ported for improved flow. Pressures to 8.6 bar (125 PSI). Flow rates up to 530 litres/minute (140 gal/min). Bolted construction for greater integrity. Robust construction.

Blagdon - Metallic Pump

Air valve designed for in-line maintenance. Available center ported. Pressures to 125 psi (8.6 bar). Flow rates 0 to 285 gallons per minute (0 to 1,078 LPM). Bolted construction for greater integrity. Robust consruction.

Non-Metallic Pumps

Blagdon - Non-Metallic Pump

Simple construction, easy to maintain, Self-priming, ideal for empting containers, Pressures to 5 bar (73 PSI), Flow rates up to 16 litres/minute (4.3 gal/min), Bolted construction for safety, Low break out pressure requirement, Reliable pneumatic air valve system

Blagdon - Non-Metallic Pump

Material options suitable for a white range of chemicals. Simple construction, easy to maintain. Self-priming, ideal for emptying containers. Pressures to 8 bar (116 PSI). Flow rates up to 152. itres/minute (40 gal/min). Flanged or screwed end connections. Reliable pneumatic air valve. Strong, robust design and bolted construction.

Blagdon - Non-Metallic Pump

Simple construction, easy to maintain. Capable of handling high S.G. and viscous fluids. Pressures to 8.6 bar (125 PSI). Flow rates up to 530 litres/minute (140 gal/min). Flanged end connections. Reliable, proven pneumatic air valve.

Blagdon - Non-Metallic Pump

Simple construction, easy to maintain. Capable of handling high-S.G. and viscous fluids. Pressures to 7 bar (102 PSI). Flow rates up to 901 litres/minute (238 gal/min). Adjustable flanged connections. Reliable, proven pneumatic air valve

High-Pressure Pumps

Blagdon - High-Pressure Pump

Robust construction, easy to maintain. Can easily handle viscous, high specific gravity, and high head applications. Smooth action, less vibration and wear. Pressures to 16 bar (232 PSI). Flow rates up to 125 litres/minute (33 gal/minute). Bolted construction for greater integrity. Reliable pneumatic air valve. Stalls against closed head without damage. Re-start on demand.

Blagdon - High-Pressure Pump

Robust construction, easy to maintain. Can easily handle viscous, high specific gravity, and high head applications. Smooth action, less vibration and wear. Pressures to 16 bar (232 PSI). Flow rates up to 350 litres/minute (92 gal/minute). Bolted construction for greater integrity. Reliable pneumatic air valve. Stalls against closed head without damage. Re-start on demand.
