BLDC Pump Co., Ltd products

Model Number: DC85D-1250. Rated Voltage: DC 12V. Working Voltage Range: DC 10-18V. Rated Current: 8.3A. Maximum Head: 5 M. Maximum Flow Rate: 10000 L/H. Noise Level: ~35dB. Liquid Temperature Range: -30~100°C. Inlet Diameter: 38mm. Outlet Diameter: 38mm. Dimensions: 220mm*129mm*162mm. Weight: 3.2kg. Pump Shell Material: PA66+30%GF (can be customized to other materials).

Model Number: DC85E-1880. Rated Voltage: DC 18V. Working Voltage Range: DC 10-24V. Rated Current: 8.3A. Maximum Head: 8 M. Maximum Flow Rate: 12000 L/H. Noise Level: ~35dB. Liquid Temperature Range: -30~100°C. Inlet Diameter: G1-1/4″ thread. Outlet Diameter: G1-1/4″ thread. Dimensions: 220mm*129mm*162mm. Weight: 3.2kg. Pump Shell Material: PA66+30%GF (can be customized to other materials).

Model Number: DC80D-24100. Rated Voltage: DC 24V. Working Voltage Range: DC 10-30V. Rated Current: 6.3A. Maximum Head: 10 M. Maximum Flow Rate: 8000 L/H. Noise Level: ~35dB. Liquid Temperature Range: -30~100°C. Inlet Diameter: 38mm. Outlet Diameter: 38mm. Dimensions: 185mm*100mm*136mm. Weight: 2.1kg. Pump Shell Material: PA66+30%GF (can be customized to other materials).

Dimensions: 93.9mm*99.5mm*69.6mm. Weight: 0.48kg. Inlet Diameter: G1/2″ thread. Outlet Diameter: G1/2″ thread. Pump Shell Material: PA66+30%GF (can be customized to other materials).

Dimensions: 100.5mm*95.5mm*69.6mm. Weight: 0.48kg. Inlet Diameter: 14mm. Outlet Diameter: 14mm. Pump Shell Material: PA66+30%GF (can be customized to other materials).

Dimensions: 115.9mm*95.5mm*69.3mm. Weight: 0.48kg. Inlet Diameter: 27mm. Outlet Diameter: 27mm. Pump Shell Material: PA66+30%GF (can be customized to other materials).

Dimensions: 51mm*34mm*42.7mm. Weight: 0.1kg. Inlet Diameter: 8mm. Outlet Diameter: 8mm. Pump Shell Material: ABS (can be customized to other materials).

Dimensions: 65mm*67mm*59mm. Weight: 0.16kg. Inlet Diameter: 12mm. Outlet Diameter: 10mm. Pump Shell Material: PA66+30%GF (can be customized to other materials).

Dimensions: 85.5mm*64.8mm*56mm. Weight: 0.23kg. Inlet Diameter: G1/2″ thread. Outlet Diameter: G1/2″ thread. Pump Shell Material: PA66+30%GF (can be customized to other materials).

Dimensions: 84.5mm*61.8mm*56mm. Weight: 0.24kg. Inlet Diameter: 11mm. Outlet Diameter: 8mm. Pump Shell Material: PA66+30%GF (can be customized to other materials).
