BoldEco Environment, Inc. products

The OptiVap™ dual-fluid evaporative gas cooling system utilizes a newly developed dual-fluid (air atomized) nozzle technology that uses 2.3 m3/h of air for every l/m of water injected. For the same droplet size generation, the closest competitive system utilizes almost 3.2 m3/h of air for every l/m of water injected, or 36% MORE AIR. That means that the OptiVap nozzle is over 30% more efficient than its nearest competitor!

The SpraySentinel ES controller is an automatic spray system supervisory system designed to monitor spray systems performance and alert plant personnel to any potential problems that might be hampering spray system performance. The SpraySentinel ES carries out a self-learning period to record how the installed lances and nozzles are respond to varying operating conditions. After a short learning period, the controller starts to detect all critical deviations of the working parameters of the cooling system and, when appropriate, to provide the operators with an alarm.

BoldEco Environment possesses a great deal of experience in the design and supply of wet, dry and hybrid semi-dry scrubbing systems. BoldEco Environment has been applying conventional wet, dry and semi-dry scrubbing technology for years now, and has recently developed patented SO2 scrubbing technology for the following markets: Power, incineration, cement, lime, glass.

Single upflow reactor coupled to fabric filter. Multiple upflow reactors coupled to fabric filter. Utilizes standard hydrated lime in recycle mode. Oxidizer reactor removes NOx and oxidizes mercury. Preheat system included to avoid acid gas dew point.

The BoldEco VersaMAPS (versatile multi-pollutant control system) is a low capital and operating cost solution for removing acid gases, nitrogen oxides, mercury (both ionic and elemental) and particulate matter (including PM 2.5) concurrently. The VersaMAPS can be implemented with integrated single-stage oxidizer NOX removal or with a second stage that utilizes ammonia-based reactants for additional NOX removal efficiency. Units consist of one to six identical sub components, which can be installed in stages consistent with regulatory deadlines and the individual needs of the plant.

Low-cost Selective Catalytic Reduction (SCR) Combined with High Temperature (HT) process filtration.

Low-cost of ownership process filtration. Available Features: long bags elements. Full-spectrum pressure cleaning (hi-med-low). On-line and off-line cleaning system. Inlet designs for high dust applications. Modular / field erected / explosion proof designs.

VEnTO Benefits - Pulse Jet Baghouse: Fully-automated, adaptive controller Full-spectrum pressure cleaning (hi-med-low) Extends bag mfg guarantee by two additional years Reduces energy consumption Enhances capture of particulate and condensables Scroll down for more information on VEnTO.

Reverse Air Baghouse Performance: Reverse-Air (or sometimes referred as Reverse-Gas) baghouses are fabric filters that use recycled clean-side gases in a counterflow manner in order to regenerate the filtration elements, and operate on either positive or negative pressure. The main advantage of a Reverse-Air Fabric Filter (RAFF) is that it can only operate in off-line mode, and thus typically avoids the particulate penetration that typically occurs during on-line cleaning.

A much more effective, flexible and reliable solution is the BoldEco Tsunami™ Impulse Generator. It is an adaptive control device installed on the reverse air duct, designed to impart a standing shockwave in the filter regeneration system that results in cleaner bags and shorter cleaning cycle without destroying the integrity of the filter cake and resulting in higher baghouse capacity.
