Brightek Optoelectronic Co., Ltd. products
Automobile Application - Ambient Lighting
Brightek - Model 6SC3433VGB00MSZ1 - Ambient Lighting
Forward current: Less then 50mA; Typical view angle 50% Iv:120; Lens color: White Diffused; RoHS2.0 and Reach-compliant; Qualified according to JEDEC moisturevity Level 2a; ESD Level 2kv (HBM); Reliability Test: AEC Q-102 Qualified.
Brightek - Model 6SD4516VGB01MAZ1 - Ambient Lighting
Forward current: red&blue&green: less then 30mA, Typical view angle 50% Iv: 120°; Lens color code: white diffused; EIA STD package; RoHS2.0 and REACH-compliant; Preconditioning: accelerate to JEDEC level 2a; ESD level 2KV(HBM)\; Reliability Test: AEC Q-102qualified.
Automobile Application - Daytime Running Light
Brightek - Model V52720W40WNZ1 - Daytime Running Light
Forward current: 240mA; Typical view angle 50% Iv: 120°; RoHSZO andREACH-compliant; Lens color: yellowish; Qualified according to JEDEC moisturevity Level 2a; ESD level 8kV(HBM); Reliability Test: AEC Q-102qualified.
Brightek - Model V52720W40WMZ1 - Daytime Running Light
Forward current: 450mA; Typical view angle 50% Iv: 120°; RoHS2.0 andREACH-compliant; Lens color: yellowish; Qualified according to JEDEC moisturevity Level 2a; ESD level 8kV(HBM); Reliability Test:AEC Q-102qualified.
Brightek - Model 5Z3433AW35END1NQ - Daytime Running Light
Forward current: 240mA; Typical view angle 50% Iv: 120°; RoHS2.0 andREACH-compliant; Lens color: yellowish; MSL 2a qualified according to JEDEC J-STD20D; ESD level 6kV(HBM); Reliability Test: AEC Q-102qualified.
Brightek - Model 5F1519AW3FFNZQNG - Daytime Running Light
RoHS and REACH-compliant; MSL2 qualified according to JEDEC J-STD 020; ESD 8KV (HBM: ANSI/JEDEC JS-001 Class 3B); AEC-Q102 Qualified.
Automobile Application - Turning Signal
Brightek - Model V52720Y85CNN1 - Turning Signal
Forward current: 200mA; Typical view angle 50% Iv: 120°; RoHSZO andREACH-compliant; Lens color: water transparent; Qualified according to JEDEC moisturevity Level 2a; ESD level 2kV(HBM); Reliability Test:AEC Q-102qualified.
Brightek - Model V52720W10WMZ1 - Turning Signal
Forward current: 450mA; Typical view angle 50% Iv: 120°; RoHS2.0 andREACH-compliant; Lens color: yellowish; Qualified according to JEDEC moisturevity Level 2a; ESD level 8kV(HBM); Reliability Test: AEC Q-102qualified.
Brightek - Model V52720W10WNZ1 - Turning Signal
Forward current: 240mA; Typical view angle 50% Iv: 120°; RoHS2.0 and REACH-compliant; Lens color: yellowish; Qualified according to JEDEC moisturevity Level 2a; ESD level 8kV(HBM); Reliability Test: AEC Q-102qualified.
