Bulgin products

The EXP 0911 and EXP A911 series are advanced flex cable connectors designed for hazardous environments, offering a range of features and benefits. Environmental Protection: These connectors provide exceptional protection against water and dust ingress, achieving an IP68 rating when properly mated with a compatible connector. User Friendly Design: The connectors feature a positive fast-acting locking ring that can be easily operated with a gloved hand
Versatile Configuration: Available in both plug and socket configurations to suit various application needs.

Inline Cable Connectors. Water and dustproof to IP68 when mated with compatible connector. Positive fast-acting locking ring - can be turned with a gloved hand. Plug or Socket. 2, 3, 4, 5, 7, 10 Contact with leading Earth on 3, 4, 5, 7 Contact versions, trailing Neutral on 5 Contact version. Screw Terminals. Choice of cable acceptance 7mm-22mm diameter depending on part code (see data for details): EXP-09 part codes 7mm-15mm diameter. EXP-A9 part codes (large cable version with strain relief clamp) 14mm-22mm diameter. Packs of Cable Glands for differing cable diameters available separately (EXP-0980, EXP-A980). EXP-0991 heavy duty Sealing Cap available separately to maintain IP rating of unmated connectors. Mate with EXP-09 or EXP-A9 Series Flex and Panel Mount Connectors, as appropriate.

Panel Mount Connectors. Water and dustproof to IP68 when mated with compatible connector. Positive fast-acting locking ring - can be turned with a gloved hand. Plug or Socket. 2, 3, 4, 5, 7, 10 Contact with leading Earth on 3, 4, 5, 7 Contact versions, trailing Neutral on 5 Contact version. Single hole fitting, anti-rotation key. Panel thickness 3mm-7mm. Supplied with high grade sealing gasket. EXP-0992 heavy duty Sealing Cap available separately to maintain IP68 rating of unmated connectors. Mate with EXP-0911 and EXP-A911 Series Flex Connectors.

Inline Cable Connector PX0737 Series 2 Contact Plug Screw Termination (Contacts Supplied Fitted) 6mm-8mm Cable Black Insert And Gland Nut. Inline Cable Connectors. Water and dustproof to IP68 when mated with compatible connector. Plug or Socket. 2, 3, 4, 6, 7, 9, 12, 25 Contact with leading Earth contact on 3 Contact Socket versions. Screw, Crimp, Crimp/Solder Terminations available depending on part code and number of Contacts. Screw contacts supplied fitted, Crimp contacts supplied loose (Crimp/Solder contacts and fitting tools available separately). Choice of cable acceptance 3.5mm-9mm diameter depending on part code (see data for details).

Vitalis: Engineered with bio-based materials for a sustainable future. PXV0729/P/04 provides a PCF reduction of 6.6 kg CO₂e per 100 units compared to the equivalent Standard Series Buccaneer part number. Inline Cable Connector. Water and dustproof to IP68 when mated with compatible connectors. Plug contacts. 9 pole. Crimp contacts, supplied loose. 3.5mm-5mm diameter cable acceptance. Cable Glands for differing cable diameters available separately individually or in packs. Cable Support accessory 12237/R available separately. PXV0733 Sealing Cap available separately to maintain IP rating of unmated connectors. Mates with Standard Vitalis  Series (PXV) and Standard Series (PX) Buccaneer Flex Connectors.

Vitalis: Engineered with bio-based materials for a sustainable future. PXV0728/P/04 provides a PCF reduction of 10.2 kg CO₂e per 100 units compared to the equivalent Standard Series Buccaneer part number. Flex Cable Connector. Water and dustproof to IP68 when mated with compatible connectors. Plug contacts. 9 pole. Crimp contacts, supplied loose. 3.5mm-5mm diameter cable acceptance. Cable Glands for differing cable diameters available separately individually or in packs. PXV0734 Sealing Cap available separately to maintain IP rating of unmated connectors. Mates with Standard Vitalis Series (PXV) and Standard Series (PX) Buccaneer Inline, Panel Mount and Flange Mount Connectors.

Water and dustproof to IP68 when mated with compatible connector. Supplied with panel sealing gasket and screw sealing washers. CAT5e shielded coupler - standard RJ45 patchcord can be plugged into rear. PX0870/E version has additional Earth wire. PX0733 Sealing Cap available separately to maintain IP rating of unmated connectors. Mate with PX0834, PX0836, PX0837, PX0838 Standard Series Flex Cable Connectors.

Standard (1500 Series), high inrush tolerant (1300 Series) and Indicator Only version (0430 Series).

Flex Cable Connectors. Water and dustproof to IP68 when mated with compatible connector. Positive fast-acting locking ring - can be turned with a gloved hand. Plug or Socket. 2, 3, 4, 5, 7, 10 Contact with leading Earth on 3, 4, 5, 7 Contact versions, trailing Neutral on 5 Contact version. Screw Terminals. Choice of cable acceptance 7mm-22mm diameter depending on part code (see data for details):. PX09 part codes 7mm-15mm diameter. PXA9 part codes (large cable version with strain relief clamp) 14mm-22mm diameter. Packs of Cable Glands for differing cable diameters available separately (PX0980, PXA980). PX0960/PX0990 Sealing Caps available separately to maintain IP rating of unmated connectors. Mates with PX09 or PXA9 Series Inline and Panel Mount Connectors, as appropriate.

Inline Cable Connectors. Water and dustproof to IP68 when mated with compatible connector. Positive fast-acting locking ring - can be turned with a gloved hand. Plug or Socket. 2, 3, 4, 5, 7, 10 Contact with leading Earth on 3, 4, 5, 7 Contact versions, trailing Neutral on 5 Contact version. Screw Terminals. Choice of cable acceptance 7mm-22mm diameter depending on part code (see data for details):. PX09 part codes 7mm-15mm diameter. PXA9 part codes (large cable version with strain relief clamp) 14mm-22mm diameter. Packs of Cable Glands for differing cable diameters available separately (PX0980, PXA980). PX0970/PX0991 Sealing Caps available separately to maintain IP rating of unmated connectors. Mate with PX0911 or PXA911 Series Flex Connectors, as appropriate.
