Carbonair - a brand by EVOQUA Water Technologies LLC products

112 sq ft Filtration Surface Area. Flow rates up to 1000 GPM nominal. 20,000 lb GAC capacity. Can be used with a variety of other filtration media. Piping for Series or Parallel Operation. Trailer mounted with internal piping. Dual Multi-round Bag Filter Included. Trailer mounted for easy transport and startup. Ideal for mobile water treatment applications.

78 sq ft Filtration Surface Area . Nominal Flow Rate 550 gpm. Hydraulic Maximum 1000 gpm. 20,000 lb GAC capacity. 10` Vessel Diameter. 17` 7` Vessel Height. Vessel Pressure Rating 125 PSI. 6` Quick Connect Camlock Fittings. Slurry in Slurry out Piping (Optional). Lifting Lugs. Sturdy Square Base. Top and Side Manways. All Steel Construction. Built to ASME code ( Code Stamp optional). Corrosion Resistant Epoxy Internal Coating . Stainless Steel Internal Piping.

50 sq ft Filtration Surface Area. Nominal Flow Rate 300 gpm. Hydraulic Maximum 600 gpm. 10,000 GAC capacity. 8` Vessel Diameter. 13` 3` Vessel Height. 6` Quick Connect Camlock Fittings. Vessel Pressure Rating 75 PSI. Slurry in Slurry out Piping ( Optional). Sturdy Square Base. Lifting Lugs. Top and Side Manways. All Steel Construction. Built to ASME code ( Code Stamp optional). Stainless Steel Internal Piping. Corrosion Resistant Epoxy Internal Coating.

28 sq ft Filtration Surface Area. Nominal Flow Rate 250 gpm. Hydraulic Maximum 500 gpm. 5,000 lb GAC capacity. 6` Vessel Diameter. 9` 10` Vessel Height. Vessel Pressure Rating 75 PSI. 4` Quick Connect Camlock fittings. Corrosion Resistant Epoxy Internal Coating. Top and Side Manways. Skid Mounted with Forklift Guides. All Steel Construction.

20 sq ft Filtration Surface Area. Nominal Flow Rate 150 gpm. Hydraulic Maximum 300 gpm. 2,500 GAC capacity. 5` Vessel Diameter. 7` 2` Vessel Height. Vessel Pressure Rating 75 PSI. 3` Quick Connect Camlock fittings. Skid Mounted with Forklift Guides. Top and Side Manways. Corrosion Resistant Epoxy Internal Coating. All Steel Construction.

13 sq ft Filtration Surface Area. Nominal Flow Rate 100 gpm. Hydraulic Maximum 200 gpm. 1,800 lb GAC capacity. 4" Vessel Diameter. 7" 2 Vessel Height. Vessel Pressure Rating 90 PSI. 2" Quick Connect Camlock Fittings. Skid Mounted with Forklift Guides. Top and Side Manways. All Steel Construction. Corrosion Resistant Epoxy Internal Coating.

7 sq ft Filtration Surface Area. Nominal Flow Rate 75 gpm. Hydraulic Maximum 150 gpm. 1,000 GAC capacity. 3"  Vessel Diameter. 7" 3" Vessel Height. Vessel Pressure Rating 90 PSI. 2" Quick Connect Camlock Fittings. Skid Mounted with Forklift Guides. All Steel Construction. Top and Side Manways. Corrosion Resistant Epoxy Internal Coating.

Carbonair`s PC Series Liquid Phase Filter Vessels are designed and manufactured in accordance with engineering standards set forth by the American Society of Mechanical Engineers (ASME). The materials used in construction are in accordance with standards established by AWWA, FDA and EPA. The PC Series vessels are ideal for applications that require pressure ratings of greater than 75 PSI. Typical applications for this line of filters include municipal drinking water treatment, industrial wastewater treatment and groundwater remediation.

Carbonair"s MPC Series Liquid Phase Carbon Vessels are high quality filters ideal for groundwater remediation, particularly in applications where the vessels must be moved periodically.  All MPC Carbon Vessels are equipped with lifting eyes and forklift tubes allowing for easy movement of these vessels on site or in a facility.  They have a lower profile than the PC Series vessels making them more compact and easy to ship.  MPC Series carbon vessels have pressure ratings ranging from 75 PSI to 90 PSI.

Carbonair`s LPC Series Liquid Phase Carbon Vessels are typically used in gravity discharge or low pressure water treatment applications. The materials used in construction are in accordance with standards established by AWWA, FDA and EPA.   Typically, Carbonair’s LPC3 and LPC3.85 are used for low flow groundwater treatment and they are an inexpensive but effective way to remove organic contamination from low flow water streams.  The LPC3 and LPC3.85 are available with reactivated or virgin carbon and other specialty carbons.
