CDR Pompe S.r.l. products

The pump model CCL/CCL-B features a lining of the wetted parts in PP (Polypropylene). The main features/strengths of this model are: Possibility of mounting single and double mechanical seals; Closed and open radial impellers; The shaft sleeve has a stainless steel core coated by transfer moulding in polypropylene; The CCL range is available in long coupled design with the possibility, via flexible coupling, to be coupled to B3 motors and in close coupled design with motors in B5 frame.

Single-stage, mechanical seal centrifugal process pumps lined with plastic and fluoroplastic materials. Available materials: PP (polypropylene), PVDF (polyvinylidene fluoride), PFA (perfluoroalkoxy). Long coupled (UCL) and close-coupled (UCL-B) execution.

Sub-ISO 2858 single-stage, magnetic drive centrifugal pumps lined in plastic and fluoroplastic material. Suitable for pumping aggressive and hazardous liquids (slightly contaminated, clean, low viscosity) for the chemical, petrochemical and pharmaceutical industries. Made with the same reliability as the UTN pumps, but suitable for discontinuous services.  The ETN Evo range can reach temperatures up to +120°. Available in monobloc version.

Single-stage, magnetic drive centrifugal process pumps lined in plastic and fluoroplastic materials. Long-coupled (UTN-L) and close-coupled (UTN-BL) execution. Installed mainly for handling clean toxic, hazardous and aggressive liquids in chemical and pharmaceutical industries where zero-leakage safety is a priority. Thanks to the bearing support it is also recommended for 24/7 applications and temperatures up to +130°.

Compact horizontal centrifugal pumps with magnetic drive in plastic and fluoropolymer materials.

Single-stage centrifugal pump with magnetic drive in close-coupled design. Stainless steel wetted parts. These pumps could be installed directly on pipes. The suction and discharge connections are in-line.
