Cimico S.L. products

Treatment

Designed by Cimico’s technical team, It stands out for its high specific surface, result of the 90 cells it owns, and its good hydraulic behavior thanks to its diameter and thickness. MOBED™ has been designed to achieve maximum treatment efficiency, given that the protected surface where the biofilm is generated is very high, which is reflected in the high nitrogen removal rates obtained by the plants already executed by Cimico. MOBED™ is manufactured in Europe under the main quality standards and with constant production quality tests.

Moving Bed Technologies

Best option for optimised treatment of organic matter and nutrients, especially for retrofitting existing reactors. It consists on creating the right conditions for the introduction of our MOBED® moving bed into the tank on which the biofilm grows for the elimination of organic matter and nitrogen.

MOBED - Wastewater Treatment With Pure Moving Bed Reactor

Wastewater treatment with pure moving bed reactor (MBBR) configuration, where both nitrification and denitrification occur in the biofilm. It consists onthe introduction of our MOBED® moving bed into the tank on which the biofilm grows for the removal of organic matter and nitrogen. 20-60% of the reactor volume can be filled with moving bed. The solution requires separate biological reactors and a subsequent secondary decanter without sludge return for solids separation.

MOBED - Wastewater Treatment With Moving Bed Reactor

Wastewater treatment with moving bed reactor configuration with activated sludge generating IFAS (Integrated Fixed Activated Sludge) effect. It consists of the introduction of our MOBED® moving bed in a tank with activated sludge, in such a way that nitrification occurs in the biofilm that grows on the moving bed and denitrification in the activated sludge in suspension, generating the IFAS effect and enhancing the nitrogen removal capacity of the solution and allowing the biological removal of phosphorus. The solution requires separate biological reactors, a downstream secondary settling tank and sludge recirculation.

SEMBBA - MBSBR IFAS

An optimised SBR with MOBED® moving bed, providing increased nitrogen treatment capacity, biological phosphorus removal and minimal IVF. A new technology that, through the incorporation of MOBED® moving bed to an SBR process, adds to the advantage of the already known compactness of an SBR, the high treatment capacity by high rate of nitrification in biofilm, maintaining high rates of denitrification and removal of phosphorus in suspension, achieving a high degree of IFAS effect and great removal of nitrogen and phosphorus. At the same time, filamentous bulking is minimised for better sludge sedimentation (IVF). This ultimately results in a smaller reactor volume. Ensuring this operation is possible thanks to an automatic control designed by Cimico, which in turn provides robustness of treatment and minimisation of energy consumption. In the case of SEMBBA®, but also the other Cimico moving bed technologies, the Cimico team will analyse the application of PURE or IFAS moving bed on a case by case basis.
