Continental Blower, LLC products

Number Of Stages: 1 thru 10 (cast). Inlet Connection: 4" (102 mm) flange, matches 125# ANSI. Outlet Connection: 2.5" (63.5 mm) flange, matches 125# ANSI. Operating Speed: 3600 rpm in direct drive (60Hz). Lubrication: Grease lubricated. Impeller Diameter: 14" (355.6 mm). Impeller Tip Speed: 246 f/s (75 m/s). Drive: Direct drive or V-belts. Vibration Tolerance: 1.5 mils peak-to-peak (5.4 mm /s). Shaft End: 0.86" (38 mm), inlet end drive standard.

Number of stage: 1 thru 10 (cast). Inlet connection: 6` (152 mm) flange, matches 125# ANSI. Outlet connection: 5` (127 mm) flange, matches 125# ANSI. Operating speed: 3600 rpm in direct drive (60Hz). Lubrication: Grease lubricated. Impeller diameter: 16` (406.4 mm). Impeller tip speed: 246 f/s (75 m/s). Drive: Direct drive or V-belts. Vibration tolerance: 1.5 mils peak-to-peak (5.4 mm /s). Shaft end: 1` 1/2 (38 mm), inlet end drive standard.

Number of stage: 1 thru 9 (cast). Inlet connection: 6` (152 mm) flange, matches 125# ANSI. Outlet connection: 6` (152 mm) flange, matches 125# ANSI. Operating speed: 3600 rpm in direct drive (60Hz). Lubrication: Grease lubricated. Impeller diameter: 24` (611 mm). Impeller tip speed: 437 f/s (133.26 m/s). Drive: Direct drive or V-belts. Vibration tolerance: 1.25 mils peak-to-peak (4.5 mm /s). Shaft end: 1` 3/4 (45 mm), inlet end drive standard.

Number of stage: 1 thru 9 (cast). Inlet connection: 6` (152 mm) flange, matches 125# ANSI. Outlet connection: 6` (152 mm) flange, matches 125# ANSI. Operating speed: 3600 rpm in direct drive (60Hz). Lubrication: Grease lubricated. Impeller diameter: 24` (611 mm). Impeller tip speed: 439 f/s (133.26 m/s). Drive: Direct drive or V-belts. Vibration tolerance: 1.25 mils peak-to-peak (4.5 mm /s). Shaft end: 1` 3/4 (45 mm), inlet end drive standard.

Number of stage: 1 thru 8 (cast) - 1 thru 11 (fabricated). Inlet connection: 8` (202 mm) flange, matches 125# ANSII. Outlet connection: 8` (202 mm) flange, matches 125# ANSII. Operating speed: 3550 rpm in direct drive (60Hz). Lubrication: Oil type with constant level (grease optional). Impeller diameter:  24` (611 mm). Impeller tip speed: 372 f/s (113 m/s). Drive: Direct drive or gear box or V-belts. Vibration tolerance:  1.25 mils peak-to-peak (4.5 mm /s). Shaft end: 2` 3/8 (60 mm ), inlet end drive standard.

Number Of Stages: 1 thru 7 (cast) - 1 thru 8 (fabricated). Inlet Connection: 12" (305 mm) flange, matches 125# ANSI. Outlet Connection: 12" (305 mm) flange, matches 125# ANSI. Operating Speed: 3550 rpm in direct drive (60Hz). Lubrication: Oil type with constant level. Impeller Diameter: 25" (636 mm). Impeller Tip Speed: 390 fps (119 m/sec). Drive: Direct drive or gear box or V-belts. Vibration Tolerance: 1.25 mils peak-to-peak (4.5 mm /s). Shaft End: 2" 3/8 (60 mm ), inlet end drive standard.

Number Of Stages: 1 thru 7 (8 for 50Hz). Inlet Connection: 14" (356 mm) flange, ANSI 125# drilling. Outlet Connection: 14" (356 mm) flange, ANSI 125# drilling. Operating Speed: 3550 rpm in direct dive (60Hz). Lubrication: Oil type with constant level. Impeller Diameter: 26" (662 mm). Impeller Tip Speed: 400 fps (122 m / sec). Drive: Direct drive or gear box or V-belts. Vibration Tolerance: 1.25 mils peak-to-peak (4.5 mm /s). Balance Piston: From 5 to 8 stages with pipe connection. Shaft End: 2" 9/16 (65mm) diameter, inlet end drive standard.

Integrally geared with hydrodynamic journal bearings. Stepless capacity control with inlet guide vanes and variable diffuser vanes. Flow range from 5,000 scfm to 30,000 scfm. Pressure to 35 psig.

Integrally geared with ceramic angular contact ball bearings. Compact design. Stepless capacity control with inlet guide vanes and variable diffuser vanes. Flow range from 1,000 scfm to 9,500 scfm. Pressure to 14 psig.
