D&L Oil Tools products

The AS-5 Packer is a compression set tool with a J-slot to control pack-off. It is run above other packers (such as the AS-III Packer) to selectively treat, produce or inject in multiple zone completions. It is also used to isolate casing hole perforations. This packer features a large by-pass area to prevent swabbing when running and retrieving. When releasing, the valve allows debris to be washed from the upper slips.

The AS-II Packer is a large-opening, compression-set packer with mechanical slip hold-downs. This packer withstands high pressure from above or below by using a 3-element packing system, and upper and lower mechanical slips. A J-slot and a drag block mechanism are incorporated for easy setting. This packer has a built-in unloader which circulates across the mechanical hold-down slips to improve retrievability. The unloader has a pressure compensating piston to keep it closed when pressure is greater below the set packer.

The AS-III Packer is a single-grip packer with no upper hold-down for use where no differential pressure from below is present. From the packing elements down, this packer operates identically to the AS-II Packer. This packer also features a large by-pass area to prevent swabbing when running or retrieving. This packer is ideal for isolating casing holes or perforations when used as the lower packer in conjunction with the Snapset Packer as the upper packer.

The ASI-X Packer is the most versatile of the mechanically set retrievable packers and may be used in any production application. This packer is suited for treating, testing, or injection applications, in pumping or flowing wells, either deep or shallow. This packer can be left in tension or compression depending on well conditions and the required application.

The ASI-X Shear Release Packer features a special J-pin ring configured for emergency release operations. Straight pull from the set position will release the tool at a designed shear value. The shear components are adjustable to fit customer needs and can be re-pinned for future use.

The Casing Packer is a large bore, single grip packer used to isolate damaged casing and for production or injection. This packer can be run in tension or compression and can be used as a liner hanger when equipped with a right-hand release sub. Coarse, deep wickered slips allow this packer to set in open-hole or scaly casing. For open-hole set, this packer can be equipped with two elongated packing elements to assure a positive seal.

The DL Tension Packer and DL Shear Tension Packer are economical, compact tools for injection, pumping, medium range treating and production applications. These packers are set by 1/4 right-hand rotation of the tubing and then pull tension. To release these packers, slack off the tubing and the packer will automatically re-jay into the release position. These packers have a right-hand rotation release allowing retrieval of the tubing string.
