DAGA Equipment products

Vertical and mechanically raked bar screen constructed out of high quality stainless steel bars for intake screening and refuse removal. The solids captured on the bar screen are removed on the top of the equipment by cleaning rakes which are moved by two lateral chains. The solids are then expelled out the shoot point. The unit housing, the translation chains and the cleaning system are designed to ensure long-term trouble-free operation. Fitted lateral sealing bands and adjustable anchoring are also provided to suit channel requirements. The amount of rakes will depend on the screening height and the operation conditions (flow, screening discharge capacity, particles sizes, density of residues to be withdrawn, etc.)

The DAGA self-cleaning traveling-screen consists of a series of overlapping self-draining screen-trays which are fastened to two lateral steel chains mounted on a structural drive. The solids captured on the screen-trays are washed from the screens by high-pressure overlapping water sprays across the back of the screen trays.The solids are expelled at the point of discharge. The equipment is composed of two opposite sides equipped with filter panels that allow the entry of water and a third side of effluent outlet. The unit housing, the translation chains and the cleaning system are designed to ensure long-term trouble-free operation. Fitted sealing bands and height-adjustable anchors are also provided to suit channel requirements.
