DeepRock Manufacturing Co. products

The smallest, all-hydraulic tophead rig on the market. Designed for 2` and 4` wells to 200` depth in easier soils and unconsolidated formations. Rated for air or mud rotary drilling. Water well drilling equipment available with gas or diesel power and in truck, single- or double-axle trailer, track or skid mount configurations.

The DR40 incorporates many of the features of the DR 100 and is designed in response to customers` desire for an even more compact drill rig.  Employing two engines, one for the hydraulic rig functions and one for the mud pump, the rig can be gas or diesel powered.  It can be fitted as a skid, single axle trailer, or mounted in the bed of a small truck.

The standard-bearer of the DeepRock line.This compact, yet powerful water well drilling rig can drill wells to 500` and employs many innovative features including the patented automatic breakout system which makes rod disconnections fast and safe.  Available with gas or diesel power.  Skid, tandem axle or truck mount are available.

The DR120 is rapidly becoming the most popular and versatile of all the DeepRock drilling rigs. The DR120 is available in skid, tandem trailer, track, or truck mount configurations and can be outfitted with either deck engine or PTO power. This rig can be outfitted with centrifugal, piston, diaphragm and screw mud pumps, water injection and on-board air compressor.

The DR150 is a drilling rig that employs as much torque and pullback capacity as many larger rigs  and can be outfitted with a variety of mud and air systems.  It is available in skid, tandem trailer, track, and truck mount versions with either deck engine or PTO power. The DR150 featured in this photo is outfitted with DeepRock`s exclusive OTTO automated drill rod handling system and a swing jib.  Suitable to be used as a gold mining drilling equipment.

The DR 30A is an auger-only version of the DR30.  Available with gas or diesel engines, it uses both solid or 2- 1/3` ID hollow stem augers.  The DR 30A is ideal for small diameter, shallow monitoring wells or soil sampling.  It comes with a 5` stroke, 18HP gasoline engine standard and a dual hydraulic pump.

 The DR 40A is an auger-only version of the DR40.  Like the DR 30A it is available with gas or diesel engines.Built on a larger frame, it uses both solid and up to 3-1/4` ID hollow stem augers.  We have larger engines available for higher torque and speeds.


With a powerful hydrostatic drive, the DR2K is designed specifically for soils investigation. It is available with cathead, automatic samplers, mast extensions, sliding base for off-hole work, grouting pumps and many other popular options. Available as a skid, single or tandem axle trailer or truck mount.

Our most popular compact rig for soils investigation, the DR 3K is a versatile rig with the capabilities of much larger rigs.  Designed to run medium range ( 4-1/4` to 6-5/8`) hollow stem augers, customers have far exceeded the depth ranges of the required design capabilities.  Available with a wide variety of accessories, the DR 3K can be equipped to truly be an all-purpose rig.  Available as a skid, tandem trailer, truck, track, deck engine or PTO.

The DR5K is the same physical size as the DR3K but with more torque for larger augers.  Additional pullback is provided for even greater depths and more safety in difficult formations.  Available as a skid, tandem trailer, truck, track, deck engine or PTO.
