DHV Industries, inc. products

DHV Side Entry Trunnion Mounted Ball Valve are designed, engineered and manufactured especially for oil and gas pipeline application. Manufactured at our API certified facility, all DHV Trunnion Ball Valves provide excellent corrosion resistance and superior sealing performance at both high and low pressures. DHV offers a wide variety of material options to meet your critical needs from Carbon Steel to Duplex Stainless Steel and Inconel, available DHV sizes from 2? to 48? in ANSI class 150-2500. DHV Trunnion Ball Valves are equipped with standard features of Double Block & Bleed, Fire Safe, Emergency Sealant Injections, NACE MR0175 compliance and ISO mounting pads to all bare stem valves for gear or actuator adaption. We are ready and eager to meet your special feature requirement like extended Stem/Bonnet, Transition Pups, Metal Seated, Fully Welded Body and Actuation.

DHV Side Entry Trunnion Mounted Ball Valve are designed, engineered and manufactured especially for oil and gas pipeline application. Manufactured at our API certified facility, all DHV Trunnion Ball Valves provide excellent corrosion resistance and superior sealing performance at both high and low pressures. DHV offers a wide variety of material options to meet your critical needs from Carbon Steel to Duplex Stainless Steel and Inconel, available DHV sizes from 2? to 48? in ANSI class 150-2500. DHV Trunnion Ball Valves are equipped with standard features of Double Block & Bleed, Fire Safe, Emergency Sealant Injections, NACE MR0175  compliance and ISO mounting pads to all bare stem valves for gear or actuator adaption. We are ready and eager to meet your special feature requirement like extended Stem/Bonnet, Transition Pups, Metal Seated, Fully Welded Body and Actuation.

Basic Design: ASME B16.34, ISO 17292, BS 5351, API 608, API 6D. Sizes: 1/2″-12″ FB/RB. Pressures: ANSI 150lb-600lb. Materials: Cast Carbon / Stainless Steel. Ends: RF, BW. Test and Inspection: API 598, API 6D. Fire Safe Design/Test: API 607. Fugitive Emission Test: ISO 15848-2. Type Testing for FE: ISO 15848-1, API 641. CSA Z245.15 latest version compliance available.

Additional information: Basic Design: ASME B16.34. Sizes: 1/2″-24″. Pressures: ANSI 150lb-2500lb. Materials: Forged / Cast Carbon / Stainless Steel. Ends: RF, RTJ, BW.

Additional information: Basic Design: ASME B1634. Sizes: 2″-24″. Pressures: ANSI 150lb-1500lb. Materials: Cast Carbon / Stainless Steel. Ends: RF, RTJ, BW. Fire Safe Design/Test: API 607

Basic Design: BS1868, ASME B16.34. Sizes: 2″-48″. Pressures: ANSI 150lb-2500lb. Materials: Cast Carbon / Stainless Steel.  Ends: RF, RTJ, BW.

Additional information: Basic Design: API 6D, Sizes: 2″-36″ ANSI 600lb-1500lb, 6″-36″ ANSI 300lb. Materials: Cast Carbon / Stainless Steel.
Ends: RF, RTJ, BW. Fire Safe Design/Test: API 6FA.

Additional information: Basic Design: API 600. Sizes: 2″-48″. Pressures: ANSI 150lb-2500lb. Materials: Cast Carbon / Stainless Steel. Ends: RF, RTJ, BW.

Basic Design: BS 1873, API 623, ASME B16.34. Sizes: 2″-24″. Pressures: ANSI 150lb-2500lb. Materials: Cast Carbon / Stainless Stee. Ends: RF, RTJ, BW.

1/2″-2″, 800lb-2500lb, Basic Design: API 602, BS5352, Test & Inspection: API 598.
