Driconeq International products

The 50S BBBD unit is a hydraulic valve that instantly redirects air into the inner tube of an RC drill pipe. Air is redirected into the inner tubes to clear blockages and lift water away from the bit face.

60S Combo Swivel MK1 is a sample and an air swivel in one unit, eliminating the need for an under head air swivel. This component is used when there is lower air capacity or where there is limited pull back stroke. The 60S MKl Combo Swivel uses top quality roller bearings, highly durable v-pack seals and has hardened sealing surfaces on the shafts, is easily serviced in field and has seal wear indicators in the housing to identify seal wear.

The pedestal swivel is used in specialized situations where standard products are not well suited. The Pedestal Swivel is unique in that it does not have any bearings in it, with a large base it is able to carry the above head assembly without placing any added forces onto or into the head spindle. Driconeq pedestal swivels use highly durable v-pack seals and have hardened sealing surfaces on the shafts and are easily serviced in field.

The 73 ARD combo swivel is a sample swivel and air swivel in one unit. II is used in the air core application. The choice of a combo swivel over a dual swivel set up can be driven by available room below the head to accommodate a side entry air swivel.

The 73 ARD side entry air swivel is used in an air core application in conjunction with a 50S TE swivel, this is a highly durable air swivel given the air supplied in the air core technique is at the lower end of the spectrum. The 73 ARD side entry air swivel uses high quality and durable roller bearings, has replaceable hardened chromed wear sleeves on the sealing surfaces and is easily serviced in field.

The swivel has a shaft bore size of 43mm that will allow a head tube of 32nb to seal internally. The 50S TE swivel is in wide use on Cubex 560-580 drills as a conventional air swivel substantially outperforming the standard issue swivel. The 50S TE swivel uses top quality roller bearings, highly durable v-pack seals and has hardened sealing surfaces on the shafts, is easily serviced in field and has seal wear indicators in the housing to identify seal wear.

The 60S TE Swivel is typically used in conjunction with 4 ½” side entry air swivel in an RC environment and will tolerate large volumes and pressures of air. The 60S TE swivel can also be used as a mud swivel in a WW application, the bore size of the shaft is approximately 61mm, allows a relatively unrestricted flow of mud into the drill string. The 60S TE swivel uses top quality load tolerating tapered roller bearings, highly durable v-pack seals, hardened sealing surfaces on the shafts, a removable seal cartridge for easy in field servicing and seal wear indicators in the housing to identify seal wear.

60S Combo Swivel MK2 is a sample and an air swivel in one unit, eliminating the need for an under head air swivel. This component is used with lower air capacity or where there is limited pull back stroke. This unit is part of the global in pit grade control package offering.

At first you might not notice the difference between our standard drill pipes and the innovative eX-Flow®. But don’t let first impressions fool you! The eX-Flow® is packed with state of the art technology that will revolutionize your drilling.

The AERZORBER uses an unique air cushion technology instead of mechanical absorption by rubber or coil springs. The end result is improved drill performance, componentry reliability and a reduction of the overall drilling costs.
