Dynatech Pumps Pte Ltd products

The top and bottom bracket are made up of casting stainless steel for maximum strength and durability. Special glass filled engineered composites (glass filled polycarbonate*) is used for impeller and diffuser. Superior strength for maximum resistance against wear and tear. Permanently bonded through a process called sonic welding, which maintains smooth passage and efficient flow through the stages. Will not corrode and very resistant to algae and mineral build up. A special polyurethane material for top bearing. Floating impeller and flat wear ring design offer superior and handling capability.

Casting Stainless Steel provides maximum strength, durability, wear and tear resistance against sand and other impurities. State of the art manufacturing process with CNC finishing. A specialized casting process maximizes the solidarity and toughness of the structure for optimum performance. The smooth surfaces of the parts produced provides high hydraulic performance and superior appearance. Finishing is done with CNC machine with a high degree tolerance capability of up to 0.55mm for excellence alignment. A special material for top bearing, intermediate bearing and neck ring provides maximum sand handling capability.

Casting Stainless Steel provides maximum strength, durability, wear and tear resistance against sand and other impurities. State of the art manufacturing process with CNC finishing. A specialized casting process maximizes the solidarity and toughness of the structure for optimum performance. The smooth surfaces of the parts produced provides high hydraulic performance and superior appearance. Finishing is done with CNC machine with a high degree tolerance capability of up to 0.55mm for excellence alignment. A special material for top bearing, intermediate bearing and neck ring provides maximum sand handling capability.

Super Sandy Pump, Maximum Sand Resistance up to 450 g/m3, Wide Operating Voltage, 160V to 240V for single phase 50 Hz, 350V to 415V for three phase 50 Hz, Specially engineered and manufactured for Sandy Wells and Wide Operating Voltage. The Floating Impeller and Materials Selection ensured an excellent resistance against sand. The Impeller and Diffuser are constructed in Engineered Composite for strength and durability. The Discharge Head and Bottom Bracket are made of casted stainless steel for strength and rigidity. The Motor Cover is made of Stainless Steel

Engineered and manufactured for continuous heavy duty operation in sandy well. The Floating Impeller and Flat Wear Ring Design ensure an excellent resistance to wear and tear against sand. The Impeller and Diffuser are constructed in special glass filled engineered composite for maximum strength and corrosion resistance against sand. The Discharge Head and Motor Adapter are made of precision casted stainless steel for superior strength, durability and rigidity. The Special Designed Composite Non Return Valve is fitted to support the weight of the water column and to protect against water hammer

Available in 6 and 8 from 5.5 kw to 92 kw. Available in both 50 Hz and 60 Hz. Easy to disassemble and rewindable. High motor efficiency. Class B insulation and IP 58 protection. Heavy duty bearings installed. High quality mechanical seal. NEMA standard coupling dimension.

Multistage centrifugal submersible pumps for clean water in 3” and 4” wells. Engineered and manufactured for continuous heavy duty operation. The Impeller and Diffuser are constructed in Engineered Composites for strength and durability. The Discharge Head and Bottom Bracket are made of Brass for strength and rigidity. The Motor Cover is made of Stainless Steel.

Multistage centrifugal submersible pumps for clean water in 4”, 6″, 8″ wells. The DX pump series is completely constructed of stamped fabricated stainless steel 304 giving the pumps the strength durability and resistance against wear and tear. The Non Return Valve is integrated in the head to support the weight of the water column and to protect against water hammer, thus safeguarding impellers and diffusers. The rubber bearings are water lubricated and have sand channels to enable the sand particles to leave the pump with the pumped liquid.

Multistage centrifugal submersible pumps for clean water in 4”, 6″, 8″ wells. The DX pump series is completely constructed of stamped fabricated stainless steel 304 giving the pumps the strength durability and resistance against wear and tear. The Non Return Valve is integrated in the head to support the weight of the water column and to protect against water hammer, thus safeguarding impellers and diffusers. The rubber bearings are water lubricated and have sand channels to enable the sand particles to leave the pump with the pumped liquid.

Multistage centrifugal submersible pumps for clean water in 4”, 6″, 8″ wells. The DX pump series is completely constructed of stamped fabricated stainless steel 304 giving the pumps the strength durability and resistance against wear and tear. The Non Return Valve is integrated in the head to support the weight of the water column and to protect against water hammer, thus safeguarding impellers and diffusers. The rubber bearings are water lubricated and have sand channels to enable the sand particles to leave the pump with the pumped liquid.
