General Pump products

Maintenance Easy Pump, Flanged for Electric Motors.

Maintenance Easy Pump, Flanged for Electric Motor.

Maintenance Easy Pump, Flanged for Gasoline Motor.

Maintenance Easy Pump, Solid Shaft.

EM Series Triplex Plunger Pump, Solid Shaft.

Triplex plunger pump with Emperor high-temp seals. Features patented “high tech” packings: dynamic low-pressure seal retainer, superior low-pressure seal, innovative intermediate ring, superior high-pressure seal.

HTS Series?47HT – 22 MM Solid?Shaft. Flows from 4.0 GPM to 5.6 GPM. Triplex plunger pump. Features patented “high tech” packings. Patented inlet/outlet valve cage. Nickel-plated inlet/outlet valve plugs. Nickel-plated forged brass manifold with exclusive lifetime warranty. Specially designed to handle rigorous duty cycles, high temperatures and chemicals. Ideal for use in carpet cleaning and other high pressure cleaning applications.

PHTCK Series 70HT – 40 MM Solid Shaft. Symmetrical power end design featuring top and bottom mounting holes allowing for easy left to right conversions. Solid Ceramic plungers. High volumetric efficiency suction/delivery valve. SAE-B hydraulic drive available. Nickel-plated forged brass manifold with an exclusive lifetime warranty. Heavy-duty tapered roller bearings. Low/High pressure packing design with integrated cooling system. Ideal for use in car wash and other high pressure cleaning applications. Also available with high temp seals.

Features: “HR” coating on manifold 30 times more resistance to salt water mist from road spray. Triplex Plunger Pump, available in 5 plunger diameters. Patent-pending, symmetrical power end design featuring top and bottom mounting holes allowing for easy left to right shaft conversion. Low-high pressure packing design with integrated cooling system, no greasing required. High volumetric efficiency suction/delivery valves featuring new spherical design of sealing areas. Splash lubrication. SAE-B hydraulic drive available with hollow splined shaft or bell housing.

SMH Series: Inlet Pressure 75-100 PSI. Max. Fluid Temperature *86° F. Inlet Port Thread 1-1/2″ G. Discharge Port Thread 3/4″ HP-Special. Shaft Diameter ..1.969″/50 mm. Stroke 2.756”/70 mm. Pump Dimensions 34.6″x23.0″x14.13″. Crankcase Oil Capacity 304 oz./9 liters. Use GP Series 220 Oil (see page 60). Shipping Weight 573 lbs.
