SiteDrain Strip drain is used where a water collection system is needed or full area drainage coverage is not necessary or practical. It can replace traditional pipe and stone for drainage collection systems. Typical applications are golf courses, athletic fields, and residential yards. Strip drains are made in 6-36`(150-1000mm) widths in rolls 50’ to 500`(16-150m) long. The core is manufactured at a thickness of 1`(25mm). SiteDrain Strip Drain is also used for highway edge drainage. Typical widths are 12-36`(300-1000mm). Rolls can run up to 500`(150m) long.

AMERDRAIN Sheet Drain is used where large surface areas require drainage. Vertical applications include basement walls and retaining walls. Horizontal applications include plaza decks and roof gardens. The entire surface area can be covered to provide maximum drainage capacities. Sheet drains are typically made in 4`(1.2m) wide sheets in rolls 50-100`(16-33m) long. The core can be 1/4” to 1/2`(6-12mm) thick. Most sheet drains also serve as protection for waterproofing material, thereby eliminating the cost of a separate protection board.

Geomembranes are the durable, dependable solution for nearly any application. Whether for decorative commercial water features or critical containment applications such as agriculture, aquaculture, mining and other water containment, geomembrane systems are easy to install and built to last. We understand the intricacies of each project and provides the experience to manage the challenges you face. With critical concerns ranging from the logistical and legislative to the technical and environmental, we provide comprehensive support to ensure your project complies with all regulations and remains within scope. This commitment to proven products backed by superior service is why so many professionals, in both the public and private sectors, have turned to our specialty products for their geomembrane.

Geosynthetic Clay Liners are innovative products consisting composites that consist of dry bentonite sandwiched between two layers of geotextile. They are available in a range thicknesses and capabilities that are engineered for a variety of lining applications. Geosynthetic Clay Liners provide an alternative to conventional Compacted Clay Liners by replacing a thick section of compacted clay with a thin layer of pure sodium bentonite. The benefits of this approach include easy installation and more useable air-space in landfill applications.
