Greenbank Energy Solutions, Inc. products

Acoustic Steam Leak Detection systems has been used successfully for decades as a valuable tool for the management of boiler tube steam leak for early tube-leak detection on coal fired boilers and is being utilized now by Combined Cycle Power Station with Heat Recovery Steam Generator (HRSG).  The system provides a means by which boiler tube leaks can be detected before they can otherwise be detected with traditional methods. The system is designed to give the maximum warning of a forced outage that is due to a tube leak. Early detection of leaks provides the time and information that will allow the engineers to identify, locate, evaluate, monitor and plan the engineering procedures to make repairs to the boiler.

The LA 202 system provides detection of boiler tube leaks when they are not detectable by traditional methods. This allows management time to plan a repair strategy and schedule a controlled outage for tube repairs, at a time which is less expensive to the plant. Providing the scheduling flexibility needed for a controlled, organized shutdown.

The HUMY 3000 is successfully used for moisture measurement in many processes, including for granules, pellets, chips, powders, dusts, and much more. Conveyor belts, screw conveyors, silos, hoppers, etc. are particularly suitable installation locations. In-line moisture measurement is also possible in batch processes. The fast measuring process with a high resolution allows a quick and easy calibration and accuracy of up to 0.1%. In addition to an automatic temperature compensation and ageing drift, the self-monitoring device also has an integrated data logger, digital output and alarm outputs, and much more. For product- or process changes, different parameters can be stored for up to 24 products or product groups.

The MF 3000 is equipped with the newest microwave technology and is used to measure the flow of quantities of solids in metallic pipes. All powders, dust, pellets and granules can be measured reproducibly, from a few kg/h up to several t/h. The MF 3000 is suitable for inline measurements in pneumatic pipelines or in free-fall.

These devices can be used for the early recognition of flow disturbances in the transport of powders, dust, pellets and granules. This can reliably prevent problems caused by blockages, an absence of material or system failures, for instance. The measurement process of the FlowSwitch 510M is based on the physical principle of the Doppler Effect. This device can reliably prevent problems caused by blockages, an absence of material or system failures, for instance.
