Ground Effects Environmental Services Inc. (GEE) products
Ground Effects Products
GEE - Electrocatalytic Oxidation System
A GEE-patented technology, the Electrocatalytic Oxidation (EOX) treatment system is a chemical-free, turnkey contaminant removal process for wastewater.
GEE - Electro Separation Cell System
The ESC is the only process in the world that can remove colloidal solids consistently from Synthetic and Oil-Based Mud (OBM). Ideal for offshore or onshore solids control on the rig, we get the ultrafines that centrifuges can`t. With the ESC system you can program the desired density output to your exact customer density specifications. The result is exactly what you require, with low maintenance and huge savings.
GEE - Advanced Oxidation Reactor
The GEE Advanced Oxidation Reactor is an integral part of the GEE innovative wastewater technology.The Advance Oxidation Reactor is a pressurized system that uses high concentration ozone. The unique reactor design creates a highly reactive environment which reduces residence time and increases efficiency. The Advance Oxidation Reactor`s smart design means more water can be treated with higher efficiencies and lower operating costs.
GEE - Silica Carbide Flat Sheet Ceramic Membrane
Membranes manufactured from pure Silica Carbide (SiC) on a flat sheet structure. This provides some unique advantages in water treatment:
GEE - Dissolved Air Flotation (DAF) System
GEE’s Dissolved Air Flotation (DAF) system is a highly efficient pre-treatment step for the separation of suspended solids and oil and grease contaminants from wastewater. The compact GEE DAF system boasts high removal rates, 99.9% runtime and a robust design. The compact DAF can either be integrated in a complete solution or offered as a single product for your wastewater treatment.
GEE - Dissolved Nitrogen Flotation (DNF) System
Replace slow and less effective Dissolved Gas Flotation (DGF’s) for oil & gas wastewater treatment with the explosion-proof Dissolved Nitrogen Flotation (DNF) system from Ground Effects Environmental Services (GEE). The GEE DNF uses nitrogen to eliminate the risk of an explosion, while being a highly efficient pre-treatment step for the separation of suspended solids and oil and grease contaminants from wastewater. The compact GEE DNF system has high removal rates, 99.9% runtime and a robust design. It is extremely effective as a post-EOX step. The DNF can either be integrated in a complete solution or offered as a single product for your wastewater treatment.
GEE - High Efficiency Oil/Water (O/W) Separators
Whatever the wastewater treatment problem, the compact, custom-manufactured oil/water (O/W) Separators from GEE are up to the task. GEE O/W Separators are built for high-efficiency, increased removal rates and low maintenance. We know achieving optimum runtimes and lower costs is important to your project and we deliver. Plus, we use M-Pak coalescing media and/or GEE Diffused Air Flotation (DAF) for maximum efficiency and easy clean out. An array of flow rates and sizes are available. As with all of our technologies, the GEE Oil/Water Separators boast the highest runtimes in the industry at 99.9%. We build our equipment to outlast and outperform.
GEE - Vertical Leaf Filter (VLF) System
The GEE Vertical Leaf Filter (VLF) System is ideal as a final step water polishing system to filter out particles smaller than one micron. The VLF produces membrane quality water without the hassle of membranes. Perfect for use after the GEE EOX wastewater treatment, the VLF is an unmanned, fully automated, turnkey package. The system is a non-membrane, non-plugging, non-fouling technology. The system continuously adds filter aid, creating a new filter surface and eliminating plugging. The VLF’s robust design means it has lower consumables, longer lifespan and lower operating costs than membrane technologies.
GEE - Model EK3 - Electrokinetic Remediation System
The GEE EK3 Electrokinetic Remediation System is a proprietary in situ remediation process for salts, metals, hydrocarbons and chlorinated hydrocarbons in soil and ground water. A GEE-patented technology, the EK3 is an extremely effective and proven alternative to the ‘dig and dump’ approach to groundwater and soil contamination. The EK3 can be used to distribute chemical oxidation and/or biosupplements for hydrocarbon remediation in clays and silt. Mobile and compact, the EK3 is scalable to any soil or groundwater remediation problem you may have — no matter how large or deep. The EK3 uses low-voltage direct current (DC) to remediate the ground and soil contamination well below criteria with low consumables and low maintenance. It’s fast, cost-efficient and can be optimized and monitored easily from your mobile phone. It’s the best onsite salt remediation treatment system on the planet.
