13 products found
Guangzhou GBPI Packaging Equipment Co., Ltd. products
GBPI - Model ZF3600 - Automatic Total Migration Tester
ZF3600 Full-automatic Total Migration Tester is applied to determinate the dissolution amount of packaging materials in different simulant soaking solutions. 1)Tableware, cans, food packaging films, tubes, etc. 2)Made from polyethylene (PE), polystyrene (PS), polypropylene (PP) or chlorinated polyvinyl chloride (CPVC). Evaporate and dry the soaking solutions to obtain residues migrated from the specimen. The residues analysis and weighing refer to dissolution indexes in application requirements of packaging products.
GBPI - Model GBH-2 - Electronic Tensile Tester
Application To test the tensile strength, peeling strength, heat sealing strength, tearing strength, piercing strength, compression strength, bending strength, and cutting strength of plastic film, composite film, tape, soft packaging material, rubber sheets, paper, non-woven fabrics and other packaging materials, widely used in industries of plastic films, food, pharmaceuticals, inspection agency, research institute, college and so on. Standards ASTM D828，ASTM E4，ASTM D882，ASTM D1938，ASTM D3330，ASTM F88，ASTM F904，ISO 37，JIS P8113，etc.
GBPI - Model LC-1 - Sample Cutter for Tensile Tester
Application This instrument cuts samples of plastic film, paper and so on in preparation for other tests, such as tensile, peeling, tearing and heat sealing etc. It is compactly structured and easy to use. The edges of sample cut out are even and smooth. Features All parts are made from high quality steel, compact structure, easy to assemble and disassemble. It is durable, labor-saving and easy to operate. The sample sizes can be cut accurately, no damage, smooth edges without burr. Sample thickness ≤300μm
GBPI - Model GM-6 - Coefficient of Friction Tester, COF tester
Introduction The coefficient of friction tester GM-6 is a measuring instrument developed and manufactured by GBPI R&D team based on various test standards of GB, ISO, ASTM and market demand. The measured friction coefficient determines the smoothness and opening difficulty of the film. and uniformity can be accurately determined, so as to correctly guide the production. It is suitable for measuring the static friction coefficient, dynamic friction coefficient and peel strength of plastic films, composite films, aluminum foils, aluminized films, plates, rubber, ceramics and other materials when sliding. Standard ISO 8295, ASTM D1894, TAPPI T816
GBPI - Model GBD-L2 - Falling Dart Impact Tester
Introduction GBD-L2 falling dart impact tester is suitable for testing materials such as plastic film or sheet and steel plate coating with a thickness of less than 1mm. Under a given height of free falling dart impact, it can measure the energy (in Quality to express results) of plastic films, thin section specimens and other materials. Through the impact resistance test, it can prevent the packaging surface from being damaged when the packaging material is impacted or dropped due to insufficient toughness of the packaging material, and effectively avoid the product from being damaged due to impact or falling in the circulation link. It can be used in scientific research, teaching, industrial and mining enterprises, laboratories, research institutes and quality supervision departments. 3.Standard ISO7765-1, ASTM D1709, JIS K7124
GBPI - Model AUTO W806 - Gravimetric Method Water Vapor Permeability Analyzer
Product introduction This product is based on the test principle of cup method water vapor transmission and is designed and manufactured according to ASTM E96 standard, provides a wide range and high efficiency water vapor transmission rate detection for low, medium and high barrier materials testing. It is suitable for the water vapor transmission performance test of films, sheets, paper, fabrics, non-woven fabrics and related materials in the fields of food, medicine, medical equipment, daily chemicals, etc. Test principle Desiccant (weight gain method) or place water (weight loss method) in the sample cup. Standard ASTM E96, ASTM D1653, ISO 2528, TAPPIT464, DIN 53122-1Water Vapor Permeability Analyzer
Model W413 2.0 - Packaging Lab Equipment High Accuracy Barrier Film Water Vapor Permeability Analyzer
W413 2.0 water vapor permeability tester is designed to test the water vapor transmission rate (WVTR) of films or sheets materials.
Model AUTO W812 - Gravimetric Method Water vapor Permeability Analyzer
This product is based on the test principle of cup method water vapor transmission, and is designed and manufactured according to ASTM E96, GB/T1037 standards, and provides a wide range and high efficiency water vapor transmission rate detection for low, medium and high water vapor barrier materials, test.
WVTR, GTR & OTR Analyzer
GBPI - Model W301 2.0 - Water Vapor Transmission Rate Test System
W301 2.0 WVTR Permeability Analyzer to test the water vapor transmission rate of films or sheets WVTR Permeability Analyzer W301 2.0 is designed to test the water vapor transmission rate (WVTR) of films or sheets materials with the principle of Gravimetric Method. Applied to: 1) Plastic film, composite film, aluminum foil, aluminized film, etc; 2) Sheet, panel, rubber, ceramics, etc; 3) Packaging containers, such as: glass, bottle, cans, boxes, etc; 4) Expanding application: solar panel, LCD film, medical patch, etc. Widely used in quality inspection organizations, drug control institutions, research institutes, packaging, thin film, food companies, pharmaceutical enterprises, personal care industry, electronics industry and so on. Standard ASTM E96/E96M, ASTM D1653, TAPPI T464, ISO 2528, DIN53122-1, JIS Z0208, YBB00092003
