High Tide Technologies, LLC. products

The HTT-300 is the most economical HTT unit. It is most commonly used to monitor manholes and lift stations. It is equipped with 4 discrete inputs and 1 optional analog inputs. The typical use for this unit is either a duplex lift station monitor where you can collect starts and run-times for two pump and have two discrete alarms such as High Level and a power fail alarm built in. It is also perfect for a simple high level alarm at a manhole or wet well. It comes with an integrated AC/DC power supply and backup battery.

The HTT-900 is the entry-level sewer lift station or meter monitoring unit. It comes with 12 discrete inputs that can be used to monitor pump run status, alarms, meters and rain gauge pulse counters. The HTT-900 also has a built-in power fail monitor and battery backup so that operators can be notified when power is lost and still monitor various alarms. For lift station monitoring the unit automatically tracks and reports starts and run times on up to 5 pumps and will issue an alarm if a single runtime exceeds the user set time limit. The HTT-900 works seamlessly with the High Tide Technologies TelemetyVIEW web interface.

The HTT-1100 is the most commonly used High Tide Technologies telemetry unit. It is equipped with 8 discrete inputs and 4 analog inputs. Optionally, it can be equipped with an additional 4 analog inputs and/or 4 discrete outputs for control applications. The HTT-1100 also has a built-in power fail monitor and battery backup so that operators can be notified when power is lost and still monitor various alarms. The HTT-1100 can be equipped with AC power supply or a solar power system. The HTT-1100 works seamlessly with the High Tide Technologies TelemetryVIEW web interface. Typical applications include: Lift station monitoring, water tank monitoring, water or natural gas pulse and flow rate meter reporting, pressure monitoring, booster and valve station monitoring, and controls.

The HTT-3100 is equipped for larger pump stations or small treatment plants. It is equipped with 28 discrete inputs, 6 analog inputs, 2 analog outputs, and 8 discrete outputs. The HTT-3100 also has a built-in power fail monitor and battery backup so that operators can be notified when power is lost and still monitor various alarms. The HTT-3100 works seamlessly with the High Tide Technologies TelemetryVIEW web interface.

The HTT-4100 is typically used for treatment plant monitoring. The base model comes equipped with 28 discrete inputs, 12 analog inputs, and 8 discrete outputs. Optional modules can be added to increase all three signal types. The HTT-4100 works seamlessly with the High Tide Technologies TelemetryVIEW web interface.
