Huber Technology Middle East (FZE) products

Screens and Fine Screens - ROTAMAT Screens

Rotamat - Model Ro1 - HUBER Fine Screen

RELIABLE AND EFFICIENT MECHANICAL SOLIDS SEPARATION WITH WELL-PROVEN TECHNOLOGY: with integrated screenings press, with integrated screenings washing, compact design. The HUBER Fine Screen ROTAMAT® Ro1 operation is based upon a unique patented system that allows combination of screening, washing, transport, compaction and dewatering in a single unit. Depending on the screen bar spacing (6 or 10 mm) and screen size (screen basket diameter of up to 3000 mm), the throughput can be individually adjusted to specific site requirements.

Rotamat - Model Ro2 / RPPS / STAR - HUBER Rotary Drum Fine Screen / Perforated Plate Screen

Reliable and well-proven inlet screen for municipal sewage treatment plants and industrial wastewater and process water screening. fine screen with wedge wire (Ro2), perforated plate (RPPS) or folded perforated plate (STAR), with integrated screenings press and screenings washing, more than 2,000 installations worldwide. The HUBER ROTAMAT® Rotary Drum Fine Screen / Perforated Plate Screen operation is based upon a unique system that allows combination of screening, washing, transport, compaction and dewatering in a single unit.

Screens and Fine Screens - Perforated Plate and Bar Screens

Model EscaMax - Belt Screen

Versatile inlet screen: Excellent separation efficiency due to its perforations, Reliable cleansing of the perforated plates with a rotating brush, Very compact system with minimum space requirements, Easy-to-retrofit into existing channels. The EscaMax® complements the well-known HUBER program for municipal and industrial wastewater screening, as it is particularly well suited in situations where excellent separation efficiency is required in deep channels with high water levels.

Huber - Model RakeMax - Multi-Rake Bar Screen

Reliable, sturdy travelling screen: Very high screenings discharge capacity, Low headloss, Low installation height above ground level even in deep channels, Control-independent safety system, The RakeMax® Screen is perfectly suited to both municipal and industrial wastewater and process water screening. The cleaning elements, attached to the chain system, can easily be adjusted to suit different requirements.

Screens and Fine Screens - STEP SCREEN®s

Huber - Model STEP SCREEN® SSV - Fine Screen

Cost-effective separation and transport of screenings Pointing-the-way and innovative screening technology. Vertical steep installation angle of 70° / 75°, For high discharge heights and deep channels, For high flow rates, Lifting of screenings at bottom level possible. The STEP SCREEN® System is widely accepted and successful due to its function and easy-to-follow operation principle as well as the simple cleaning method without any aids (self-cleaning effect according to the counter-current principle). It is furthermore easy to maintain and able to handle extremely big screenings volumes whilst it also offers a high operational reliability. The motor linkage drive has been developed from the well-proven and patented link system. To the benefit of our customers we intentionally avoided difficult-to-maintain chain drives. With the linkage type we are able to master the occurring bending moments on the lamellas, especially with high water levels.
