Hydro Prokav Pumps India Private Limited products

Hydro Prokav KM 2000 Series pumps are built with rugged gear-type universal joint which is the effective solution to handle heavy radical thrust loads. This design ensures best performance with very minimal maintenance, low wear & Tear of rotating parts and longer life of pump.

Hydro Prokav L-Frame pumps have stood the test of time for over 15 years meeting thousands of application challenges. Performance - enhancing and cost-saving features provide outstanding benefits that maximize operating efficiency and save time and money.

Hydro Prokav progressive cavity pumps are compact, rugged and powerful. They are available in different power classes and material of construction. They prove their value world-wide in public and industrial waste water treatment and waste disposal . They provide optimum solutions for transferring fluids in the chemical and petrochemical industry, the food industry, the cosmetics industry, the paper industry, in civil engineering, mining, industrial processing and everywhere where the conveyed product is too viscous and with too poor flowing properties to be pumped by other pumps.

Hydro Prokav`s Pumping Principle involves the use of a precision - manufactured Metallic Single Helical Rotor which turns inside a double Internal Helical Resilient Stator. It therefore forms cavities confined by a `Sealing Line`. The sealing line is maintained when standstill, as well as in motion. The cavity created between the rotor and the stator during rotation moves from suction to delivery side, carrying the medium safely.

The KYM-F, WF, BB & FCC series pumps are manufactured exclusively for use in food, beverage and cosmetic industries. The construction is simple, and the focus is on effective and fast cleaning.The metallic parts in contact with the media are of 316- 304 stainless steel with the characteristic smooth finish of Hydro Prokrav. Wide- throat Hopper Inlets comprising coupling rod mounted augers can be provided for media that are highly viscous in nature.

Hydro Prokav Pumps takes its place among the largest manufactures of Progressive Cavity Pumps. Our expertise in designing and manufacturing ensures you of an extensive range of Retrofit Spare Parts for Progressive Cavity Pumps of all types. With its enhanced engineering technology, Hydro Prokav does not merely re - engineer - it gives distinct solutions. Hydro Prokav is always preferred by users of PC Pumps for its quality that exceeds expectations, each time.

Our Internal Gear Pumps belongs to family of Positive Displacement Pumps where in driving gear with internal tooth drives the internal Gear and turns in same direction inside the pump casing.During the rotation of the driving gear the liquid intake takes place at the suction and during the gear meshing, the liquid is displaced outside in the delivery side.

The working principle of Hydro Prokav dual flow Twin Screw Pumps is dependent on the rotation of the two screw spindles in the closed compartment. There is always a predefined fine clearance exists between the outside diameters of the screw spindles and the casing bore/ liner in which the screw spindles are located. Each half of the screw spindles is left handed and right handed thus when the spindles rotates, driven by the timing helical gears located at the end of the screw. The liquid is drawn towards the end of the screw and entrapped between the bore of the pumping compartment as well as the flanks of the screws and is then propelled axially from both the ends towards the centre. Such a dual flow nullifies the axial thrust completely, thereby enabling the screws to remain in a state of hydraulic balance resulting in high volumetric efficiency and overall efficiency.
