Intra-Automation GmbH products

Itabar Steam Flow Sensors are designed to operate in environments with temperatures up to 650°C and 400 bar pressure. Various designs and materials can be selected to adapt customers requirements.

Itabar Liquid and Gas Flow Sensors are designed to operate in environments with temperatures up to 1175°C and 400 bar pressure. Various designs and materials can be selected to adapt customers requirements.

When installed properly, the ITABAR sensor offers an array of advantages over other measurement systems with respect to its accuracy, pressure loss, and installation. The following guide line is designed to help you with the sensor installation and operation. The ITABAR flow sensor is so constructed, that all  cross sections have a min. diameter of 8 mm (Fig.1). So it ´s guarantee, that condensate with a  max drop diameter of 6,5 mm can flow back from the condensate pots into the flow sensor. So it can  continuous a change of condition of aggregation from liquid to steam. (Prandl,L. "Führer durch  Strömungslehre).

The IS210-P ultrasonic flowmeter is a further development of the IS200-P. This series is characterised by a more compact design and a simplified control guidance.

The IS210-S ultrasonic flowmeter is a further development of the IS200-S. This series is characterised by a more compact design and a simplified control guidance.

The ITA level indicators offers a reliable, accident-free and maintenance-free usage through a simple and break-resistant construction at a maximum process pressure of 320 bar and a temperature range from -50 °C through 400 °C. The fluid level is indicated directly with a separation of the measurement and indication area. The magnetic transfer of the fluid level from the tank to the indicator is continuous and vibration- resistant, even in the case of fast changing levels.

The ITA-T1S Liquid Level Transmitters, vertically mounted in the tank and cable-connected (3-wire) to a remote receiver operates on the float principle. A float guided on a non-magnetic tube follows the level of the liquid surface, thereby actuating the reed switches located inside the tube by means of a built-in magnet system.

The ITA T1R is a multi float ball Level Switch. The total of 6 Switch Points for media up to 100°C and 0,5 kg/dm³ can be combined in one instrument.

The Maglink Tank Level Gauge is available in 3 basic versions, designed for ATEX and German Lloyd Certified environments.

Installing a Pitot Tube Flow Meter with a Purge Unit, controlled by our DigiFlow computer is an economical solution for measuring contaminated flows.
