Jeulin SA products

Dispensing unroller: Conveyor 19 removable bars with guide. Chain protection plate. Rear removable plate. Full bottom. Bales retaining tube.

Mixing – Dispensing: Vertical conic mixing screw equipped with 7 blades and with an adjustable scraper. 540 rpm gear = 32 turn at the screw (8, 14, 16, 18 et 21 m3). 540 rpm gear = 22 turn at the screw – 1000 rpm gear = 40 turn at the screw (10 , 12 et 14 m 3). Conic circle with an anti-flood ring inserted in the vat. Fiber hoop: Angle reverser reducer with oil bath  (tank capacity 4l). 2 manual vertical contra-rotating blades. Tangential unloading trap door front right hand side or rear left hand side. Front left control ladder (or rear central if front conveyor).

Mixing – Dispensing: Vertical conic mixing screw equipped with 7 blades with an adjustable scraper. 540rpm gear = 32 turn at the screw. Conic circle with an anti-flood ring inserted in the vat. Fiber hoop: 2nd scraper on each screw. Angle reverser reducer with oil bath  (tank capacity 4l). 2 manual vertical contra-rotating blades. Tangential unloading trap door front right hand side or rear left hand side. Front left control ladder (or rear central if front conveyor).

Cutting system: 2 drums rotary mower (2×4 blades, oil bath case, free wheel incorporated. Cutting width2100 mm. Height setting of the rotary cut thanks to 2 hydraulic cylinders. Cutting system suspension by 2 springs. Cutting indicator position. Conveyor width 950 mm composed of 6 combs equipped with 8 teeth and 8 blades. Hydraulic driving of the conveyor by an hydraulic moto reductor with oil bath. Cutting system protection cover.
