Kirloskar Brothers Limited (KBL) products

GK pumps conform to ISO: 5199 & dimensionally are fully conforming to ISO 2858/EN: 22858. These pumps equip a horizontal back pullout design and radially split, single stage, centrifugal end suction volute with top centerline delivery. Pump feet are integrally cast with delivery casing. Impeller is of an enclosed type. Bearing housing is fitted with a support foot. Pump shaft is supported by grease lubricated anti-friction deep groove ball bearings as a standard scope of supply. GK pumps are mainly used for clean and clear liquids, which are free from suspended solids particles.

Kirloskar Air Cooled Thermic Fluid AT series of process pumps come with a back pull out design, which enables to remove the rotating unit of pump for inspection and repairs without disturbing suction and delivery pipe connections.

Kirloskar UP series are horizontal split casing type pumps with suction, discharge nozzles and their supporting feet integrally cast in the lower half casing. This construction enables to remove the rotating unit for inspection and repairs by just removing upper half casing and without disturbing alignment, pipe connection or prime mover.

Kirloskar multistage side channel CF pumps are capable of handling aerated liquids. CF pumps have been developed especially for heavy duty applications in all industrial areas. The pump is capable of handling clean, slightly contaminated or aggressive liquids without any problem under the most difficult operating conditions. The multi-stage side channel CF pump is very reliable and easy to maintain. CF pumps are of great importance in areas where high security and prompt service is indispensable.

Kirloskar SHS solid handling pumps are vertical non-clog pumps for wet pit applications. The pumps unit is suspended by a column pipe which also protects the transmission shaft. SHS Solid handling pumps are available with column length up to 6.5 metres. SHS solid handling pumps are manufactured to close tolerances and as per rigid specifications.

Vertical Inline pump has vertical shaft, with the suction and discharge connections in the casing in-line with each other. Kirloskar INIL pumps are designed for non-explosive clean and thin liquids without any solid particles. KBL vertical inline pump volute casing is robust in construction to avoid stress by pipe work and have radial suction port and radial discharge port. The enclosed impellers are dynamically balanced with extra smooth surface finish to ensure high efficiency.

Kirloskar NS submersible pump is used for sewage and seepage application. NS submersible pumps are single stage, single suction pumps. NS submersible pump impellers are of non-clog type which allow smooth passage of solids and cater to wide range of applications. NS pumps can be offered in stationary as well as transportable arrangements. The stationary arrangement is supplied with pump connector unit and the connector unit is connected to pump support bracket with a rubber diaphragm to make it leak proof joint.
