26 products found
Körting Hannover AG Products
-
Ejectors and Vacuum Blowers Technology
-
Gas Jet Ventilator
Using a gaseous motive medium, gas jet ventilators suck off large gas volume flows. This is possible because only slight pressure differences must be ...
-
Gas Jet Vacuum Ejectors
Gas jet vacuum ejectors remove gases and/or vapours from process operations thereby generating a vacuum in the reactor. The suction flow is compressed to a higher ...
-
Gas Jet Liquid Ejector
A gaseous motive medium is used to suck and transport ...
-
Steam Jet Ventilator
Using water vapour as a motive medium, steam jet ventilators remove very large gas volume flows. This is possible because only slight pressure differences must be ...
-
Steam Jet Compressor
Using water vapour as motive medium, steam jet compressors compress gases and/or vapours with large pressure ...
-
Steam Jet Vacuum Ejector
Steam jet vacuum pumps remove gases and/or vapours from process operations thereby generating a vacuum in the reactor. The suction flow is compressed to a higher ...
-
Steam Jet Liquid Ejector
Water vapour as motive medium is used to suck and transport ...
-
Liquid Jet Ventilator
Liquid jet ventilators using a liquid as motive medium suck off large gas volume flows. This is possible because only slight pressure differences must be overcome. Simultaneously dust, deposits and vapours can be washed out of the suction ...
-
Liquid jet vacuum pump
Liquid jet vacuum pumps suck off gases and/or vapours from a process. The lowest possible suction pressure in the reactor is only limited by the vapour pressure of the motive liquid. It is possible to compress to atmospheric or even higher ...
-
Liquid Jet Liquid Ejector
Liquid jet vacuum ejectors suck off gases and/or vapours from a process. The lowest possible suction pressure in the reactor is only limited by the vapour pressure of the motive liquid. It is possible to compress to atmospheric or even higher ...
-
Liquid Jet Solids Ejector
A liquid motive medium is used to convey solids. The solids are either introduced via a funnel or they can also be sucked in. A carrier medium e.g. water or air is mixed in to improve the delivery ...
-
Mixing Condensers
In mixing condensers condensation of the vapours takes place in direct contact with the cooling water. Cooling water and condensate are mixed together. As a measure to reduce fresh- and waste water requirements such systems can be designed with a closed cooling water loop and then it is only necessary to discharge the surplus ...
-
Surface Condensers
In surface condensers there is no direct contact between the vapours to be condensed and the cooling water. Surface condensers in multi-stage steam jet vacuum systems are built as shell & tube condensers. The temperature difference between condensation and cooling water is greater than that in the mixing-type condensation ...
-
Vacuum Systems With Mixing Condensers
The system shown in the sketch achieves a suction pressure of 1 mbar. The temperature of the available cooling water determines which pressure can be reached in the first mixing condenser. In this example, two ejector stages have been series-connected to achieve a suction pressure of 1 mbar with the lowest possible use of motive flow. Two further ejector stages compress the non-condensable components of the suction flow from the first mixing condenser ...
-
Vacuum Systems With Surface Condensers
The system shown in the sketch achieves a suction pressure of 1 mbar. The temperature of the available cooling water determines the pressure which can be reached in the first surface condenser. In this example, two ejector stages have been series-connected to achieve a suction pressure of 1 mbar with the lowest possible use of motive flow. Two further ejector stages compress the non-condensable components of the suction flow from the first condenser up ...
-
Ice / Dry Condensation Vacuum Systems
Ice / dry condensation systems operate continuously to generate and maintain the vacuum during the deodorising process of edible oils, for the freeze-drying process and for solvent recovery. Pre-connected ejectors are not required as the suction flows are frozen in the ice ...
-
Vacuum Refrigeration Plants
Steam jet chilling systems operate according to the principal of flash evaporation and are used for the economical cooling of liquids, e.g. to generate chilled water at temperature ranges down to the freezing ...
-
Fitted Steam Jet Heater
These heaters are to be installed in a liquid tank. Steam flowing through the nozzle is expanded to produce low pressure at the outlet. This causes the neighbouring liquid to be sucked in. Steam condenses thereby heating the liquid which, when flowing out of the heater, achieves a further intermixing action in the ...
-
Steam Jet Flow Heater
To be installed in piping systems. Liquid flows through the heater and steam is pressed into this liquid through the bore-hole of a condensation nozzle. The condensing steam then effects a direct heating of the ...
-
Model Series ORK - Fitted Steam Jet Heater
To be installed in a piping system. Liquid flows through the ORK; steam is introduced into this liquid by means of slim tubes. The flow around the tubes causes a gentle condensation and - as an extra advantage - low-noise operation during strongly fluctuating steam ...
-
Waste Gas Cleaning and Environmental Technology
For many decades now the increasing number of possible applications of the Körting Hannover AG has distinguished themselves in diverse branches of industrial exploitation with great success. In this context, we also provide an essential contribution towards the observation of emission regulations and therefore also protection of the environment. In the area of Caustic Recovery Plants we have installed up to now more than 160 plants world-wide and we can look back on nearly 60 years of engineering experience.
-
Jet pumps for waste water aeration
In the case of waste water aeration Körting Ejectors fulfil the highest demands that effluent and sewage treatment plants can make on an efficient and reliable oxygen transfer ...
-
Jet Pumps for Introducing Ozone
The introduction of ozone into liquids is an ideal operational field for liquid jet gas compressors. An ozone/air or ozone/oxygen mixture of approx. 10% is taken from the ozone generator, vigorously intermixed with the flow requiring treatment and then finally supplied under a higher pressure to the downstream ...
-
Off-Gas Purification Jet Scrubbers
Jet scrubbers are utilised for basic operations such as: Cooling - Scrubbing - Conveying. Exhaust air is accelerated by means of impulse exchange with t he motive-/rinsing liquid. This suction effect facilitates a gas-side pressure gain with which flow resistances can be compensated for. The action of atomising the rinsing liquid into the cylindrical part of the scrubber causes it to be filled with a fine misty cloud, so achieving the necessary large ...
-
Off-Gas Purification Venturi Scrubber
The Venturi scrubber is utilised to separate dusts and hazes with particle sizes of less than 3 µm. Amongst other things, dedusting is dependent on: particle diameter and -density, droplet diameter and -quantity, the relative velocity between particles and ...
-
Swirl Droplet Separator
Gas entering the droplet separator is set in rotation by a specially formed twist generator which causes droplets to be propelled outwards as a result of the centrifugal action. The separator chamber is shaped as a spiral tube. Droplets caught on the walls converge to form a liquid film which runs downwards towards the discharge point and not upwards in the direction of the gas flow. This special feature guarantees an effective rinsing of the ...
-
Caustic Recovery Plants (CRP)
During the mercerising process the diluted caustic soda (weak lye) from the stabilisation compartment is normally drained. Körting has found a way to recover this diluted caustic soda by evaporating water. We have been supplying Caustic Recovery Plant for mercerising lye to the textile industry since 1956 and have installed approx. 200 systems world-wide. As shown in the sketch below, the Caustic Recovery Plant (CRP) separates the weak lye (wash ...
