Lakeview Engineered Products Inc products

Construction: 316L stainless steel for all wetted parts. Side mounted heating elements: mounted externally. Insulation: 2” foil backed, 850°F, .30 conductivity, .043 SI units. Exhaust blower housing: heavy gauge, tig welded stainless steel. Impeller: self-cleaning backward inclined radial blade design. Stack connection: 6” I.D. flanged. Fluid transfer pump: (optional on E-100) air operated diaphram pump, 1/2” FPT. Blower motor: 3/4 hp, 3ph, 1725 rpm. Control panel: NEMA 4, industrial duty.

Construction: 316L stainless steel for all wetted parts. Side mounted heating elements: mounted externally. Insulation: 2” foil backed, 850°F, .30 conductivity, .043 SI units. Exhaust blower housing: heavy gauge, tig welded stainless steel. Impeller: self-cleaning backward inclined radial blade design. Stack connection: 6” I.D. flanged. Fluid transfer pump: air operated diaphram pump, 1/2” FPT.

Construction: 316L stainless steel for all wetted parts. Side mounted heating elements: mounted externally. Insulation: 2” foil backed, 850°F, .30 conductivity, .043 SI units. Exhaust blower housing: heavy gauge, tig welded stainless steel. Impeller: self-cleaning backward inclined radial blade design. Stack connection: 6” I.D. flanged. Fluid transfer pump: air operated diaphram pump, 1/2” FPT.

Construction: 316L stainless steel for all wetted parts. Side mounted heating elements: mounted externally. Insulation: 2” foil backed, 850°F, .30 conductivity, .043 SI units. Exhaust blower housing: heavy gauge, tig welded stainless steel. Impeller: self-cleaning backward inclined radial blade design. Stack connection: 6” I.D. flanged. Fluid transfer pump: air operated diaphram pump, 1/2” FPT. Blower motor: 3/4 hp, 3ph, 1725 rpm.

Construction: 316L stainless steel for all wetted parts. Heating elements: immerson heater, flanged, compatible alloy sheath. Insulation: 2” foil backed, 850°F, .30 conductivity, .043 SI units. Exhaust blower housing: heavy gauge, tig welded stainless steel. Impeller: self-cleaning backward inclined radial blade design. Stack connection: 6” I.D. flanged.

Tank construction: 10 gauge, 316L stainless steel construction. Heat exchange tube: 10 gauge, 316L stainless steel construction. Access and blower lid: stainless steel for all wetted parts. Insulation: 2” foil backed, 850°F, .30 conductivity, .043 SI units. Exhaust blower housing: heavy gauge, tig welded stainless steel. Impeller: self-cleaning backward inclined radial blade design. Stack connection: 9” I.D. flanged.

Tank construction: 10 gauge, 316L stainless steel construction. Heat exchange tube: 10 gauge, 316L stainless steel construction. Access and blower lid: stainless steel for all wetted parts. Insulation: 2” foil backed, 850°F, .30 conductivity, .043 SI units. Exhaust blower housing: heavy gauge, tig welded stainless steel. Impeller: self-cleaning backward inclined radial blade design. Stack connection: 14” I.D. flanged.

Tank construction: 10 gauge, 316L stainless steel construction. Heat exchange tube: 10 gauge, 316L stainless steel construction. Access and blower lid: stainless steel for all wetted parts. Insulation: 2” foil backed, 850°F, .30 conductivity, .043 SI units. Exhaust blower housing: heavy gauge, tig welded stainless steel. Impeller: self-cleaning backward inclined radial blade design.

Construction: stainless steel for all wetted parts. Heat exchanger: 3/8” grade 316L stainless steel, 150 psi maximum pressure, A.S.M.E. Section VIII specifications, “U” stamped. Insulation: 2” foil backed, 850°F, .30 conductivity, .043 SI units. Exhaust blower housing: heavy gauge, tig welded stainless steel. Impeller: self-cleaning backward inclined radial blade design.
Stack connection: 10” I.D. flanged.

Construction: stainless steel for all wetted parts. Heat exchanger: 3/8” grade 316L stainless steel, 150 psi maximum pressure, A.S.M.E. Section VIII specifications, “U” stamped. Insulation: 2” foil backed, 850°F, .30 conductivity, .043 SI units. Exhaust blower housing: heavy gauge, tig welded stainless steel. Impeller: self-cleaning backward inclined radial blade design. Stack connection: 10” I.D. flanged.
