Link-Belt Cranes products

Greaseless 38 ft – 115 ft (11.6 m – 35 m) full-power four-section boom. Two-piece manual offsetable fly is available with offset positions of 2°, 15°, 30°, and 45° with no capacity deducted for stowed attachment.

Greaseless 38 ft – 142 ft (11.6 m – 43.3 m) full-power five-section boom. Two-piece manual offsetable fly is available with offset positions of 2°, 15°, 30°, and 45° with no capacity deducted for stowed attachment. Fully rigged transports under 100,000 lbs (45 359 kg) with counterweight installed

Greaseless 38 ft – 142 ft (11.6 m – 43.3 m) full-power five-section boom. Optional two-piece SmartFly is available with offset positions of 2°, 15°, 30°, and 45° with no capacity deducted for stowed attachment. Fully rigged transports under 105,000 lbs (47 627 kg) with counterweights installed. Ergonomic operator’s cab designed with the operator in mind.

Greaseless 36.8 ft – 115 ft full-power four-section formed boom (five feet longer than predecessor). Manually offsetable one- or two-piece fly: offsetable to 2°, 20°, and 40°. Full fly is stowable on the machine, and no capacity deducts for stowed attachment.

36.8 ft – 115 ft full-power greaseless formed boom (five feet longer than predecessor). 28.5 – 51 ft two-piece onboard fly. Full fly is stowable on the machine, and no capacity deducts for stowed attachment. 171 ft maximum tip height with full attachment. Transports fully equipped at under 84,000 lbs with 18,400 lb counterweight.

Greaseless 41 ft – 127 ft pin and latch four-section boom. Manually offsetable one- or two-piece fly: offsetable to 2°, 15°, 30°, and 45°.  Full fly is stowable on the machine, and no capacity deducts for stowed attachment.

Greaseless 41 ft – 127 ft pin and latch four-section boom. Manually offsetable one- or two-piece fly: offsetable to 2°, 15°, 30°, and 45°. Full fly is stowable on the machine, and no capacity deducts for stowed attachment.

Greaseless 42.7 ft – 197.3 ft pin and latch six-section boom. Three-piece (10 ft – 32.5 ft – 55 ft) fly with integrated heavy-lift section: manual OR hydraulic offset options. One, two, or three available lattice inserts to achieve max tip height of 315.1 ft.

Full-power 36.8 ft – 115 ft (11.2 m – 35.1 m) four-section boom with two boom extend modes (EM1, EM2). Greaseless boom includes Link-Belt’s proven Teflon-impregnated wear pads for easy maintenance. Durable textured and slip-resistant paint on all walking surfaces is new and improves footing.

Four-section 38.6 ft – 120 ft (11.8 m – 36.5 m) full-power boom — maximum tip height of 184.5 ft (56.2 m) with SmartFly. V-CALC offers variable side frame track positions. TCC-800 offers optional one- or two-piece 35 ft – 58 ft (10.6 m – 17.6 m) fly.
