Lucon, Inc. products

Capacity: 14,000 Lb, 16,000 Lb, 30,000 Lb. Extension: Manual, Manual, Manual With Roller. Overall Width: 96”/102”, 96”/102”, 96”/102”. Length: 22’ – 32’, 21’ – 31,’ 27’ – 42’. Main Frame: Tube, Tube, Tube.

Capacity:10,000 Lbs.12,000, Lbs.14,000 Lbs.. Overall Width:98” / 102”,  Optional 98” / 102”,  Optional 98” / 102” Optional. Deck Length:14’ – 20’, Flat14’ – 20’,  Flat14’ – 20’ Flat. Main Frame:6”, 6”, 6”. Tilt Deck Frame:Formed, Formed, Formed

Capacity:8,000 Lbs.10,000, Lbs.12,000, Lbs.14,000, Lbs. Overall Width:98” / 102”, Optional 98” / 102”,  Optional 98” / 102”, Optional98” / 102”, Optional. Deck Length: 14’ – 20’ , Flat 14’ – 20’,  Flat 14’ – 20’,  Flat 14’ – 20’ Flat

Capacity:20,000 Lb. 40,000 Lb. 45,000 Lb. Overall Width: 96/102,102,102. Deck Length :20’ Flat 5’ BT ,24’ Flat (Stationary Deck Optional) ,24’ Flat (Stationary Deck Optional)

Capacity: 20,000 lbs. Overall Width: 102”. Deck Length: 17’ Flat / 3’ BT. Main Frame: 8” @ 21 I Beam. Cross Members: 3” Channel. Axles: (2) 10,000 lb. Torflex or (2) 10,000 lb. Air Spring. Suspension: Torflex / Spring on Air Brake. Brakes: 12 ¼ ” x 3 3/8” Electric. Tires: 235 75R 17.5 on single (8 Bolt). Jack: 12,000 lb. Tool Storage: Lockable Storage in Tongue. Hitch: Adj. 3” Pintle Ring. Tie Downs: (7) 1” D rings. Lights: LED. Wiring: Sealed Modular Harness. Paint: Black or CAT Yellow. Option: Air Brake, (2) Dexter 10,000 Lb. Axles, Suspension 20,000 Lb. Slipper Spring

Capacity: 20,000 lbs. Overall Width: 102”. Deck Length: 30’ – 40’. Main Frame: 12 @ 19 Beam. Axles: 10,000 lb. Suspension: Slipper Spring. Brakes: Electric / Air. Tires: 235 80R 16 (8 Bolt). Jack: Dual. Hitch: Adj. 3” Pintle Ring. Tie Downs: 4” Straps. Lights: LED. Paint: Black or CAT Yellow

Capacity: 7,000 lbs. Overall Width: 88”. Deck Length: 10’. Main Frame: 6”. Tilt Deck Frame: Formed. Cross Members: 3” Channel. Axles: 3,500 Lb. Suspension: Torflex. Brakes: 12” x 2” Electric. Tires: 225 75R 15 (6 Bolt). Jack: 12,000 lb. Hitch: Adj. 2 ½” Pintle Ring. Tie Downs: (2) 5/8” D Rings per Side. Tilt Cylinder: 2” x 8” Cushion Cylinder. Load Wedge: 16 ½” x 30”. Lights: LED. Wiring: Sealed Modular Harness. Paint: Black or CAT Yellow.

Capacity: 8,000 lbs. Overall Width: 102”. Deck Length: 25’ – 40’. Main Frame: 7” Tube. Axles: 6,000 lb. Suspension: Slipper Spring. Brakes: 12” x 2” Electric. Tires: 235 80R 16 (8 Bolt). Jack: 12,000 lb. Hitch: Adj. 2 ½” Pintle Ring. Tie Downs: 4” Straps. Lights: LED. Wiring: Sealed Modular Harness. Paint: Black or CAT Yellow.

Capacity: 50,000 Lb. / 54,000 Lb. . Overall Width: 102″ 102″. Deck Length: 22′-30’ Flat / 5′ -7’ B.T.  Main Frame: 14″@26 I-Beam.
Siderails: 8″Channel. Crossmembers: 5″ Channel . Axles: (3)22,500 Lb. Brakes: 12 1/4″x7 1/2″ Air w/ABS 2S 1M. Suspension: Hutch 9700. Tires: 215/75R17.5 Hub Pilot . Jack: 2-Speed Set. Ramps:  20 1/2″”x60″ Ladder / Wood Fill. Tool Storage: Lockable Toolbox in Tongue. Hitch: Adj. 3″ Pintle Ring. Safety Chains 1/2″ Gr. 70 w/Safety Hooks. Tie Downs: (5) 1″ D-Rings Ea. Side. Lights: LED. Decking: 2″ Nominal Oak. Paint: Black or Cat Yellow(Other Colors Optional). Options: Air Lift AxleHydraulic or Air Lift RampsExtra Long Bi-Fold Ramps
