Magnolia Trailers products

STANDARD FEATURES: Length: 40` or 42`. Main Frame: 16"  36# beam with truss ATMS Grade 572 Steel. Bolster: 8`6" wide 4 x 10 x 5/16 square tubing crossmembers, 5 x 5 x 5/16 tubing uprights. King Pin: 18" setting.  Bumper: Full width.  Drag Bar. Grab Bar. Stand: Load bearing roll forward under neck or back. Suspension: Hutch 9700 underslung 4 spring with heavy-duty 3 leaf springs. Axles: 25000# Outboard 10 Hole Budd with 30/30 brakes and ABS braking system. Tires: 11R24/5. Lights: D.O.T. approved with reflective tape.  Winches: Included with straps or cables. Color: Customer choice.

Standard Features: Length: 44½ Overall 14½ Motor Grader Ramps 28` Flat Deck with a 3½ Dovetail. Width: 8½6`. Capacity: 35 Ton. Main Frame: 16 40# Beam 20½ Hitch Slope. Side Rails: 10` Channel Crossmembers 6` 8.5# I-Beams. Deck: Flat 2` Oak Floor with Covered Wheels 5/16 Plate with ½ Square Bar Traction Cleats. Suspension: Hutch 9700 Underslung with heavy duty 3 Leaf Springs. Tires: 255/70R22.5 Low Profile Radials 16 Ply. Deck Height: Empty 39`. Land Gear: 2 Speed with Sand Shoes. Lights: D.O.T. approved . Ramps: Spring loaded. Color: Customers choice. Company Name on Side. D Rings as Specified.

Standard Features: Length: 28` or 42` between Bolsters. Bolster: 8½6` wide, 8` Load High Front, 7` Rear. King Pin: 1/2`. Suspension: 50,000 lb.Hutch H-900 Single Point. Axles: 25000 lb. Outboard Budd UNI Mount Auto Slacks ABS. Tires: 11R 24.5 New Radial. Tail Light Bar with Mud Flaps. Stand: Non-Load Bearing. Lights: DOT Approved, All Sealed Beam. Color: Customer Choice.
